Sony HCD-VX88 - (6) BASE UNIT SECTION (BU-K2 BD37 A)

67
(6) BASE UNIT SECTION
(BU-K2BD37A)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
0 251 8-820-116-01 OPTICAL PICK-UP KSM-213DAP/Z-NP
252 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
253 A-4725-001-A BD BOARD, COMPLETE
254 4-951-620-01 SCREW (2.6X8), +BVTP
252
254
253
251
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
