75
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C886 1-136-165-00 MYLAR 0.1uF 5% 50V
C887 1-130-777-00 MYLAR 0.1uF 10% 100V
C888 1-130-777-00 MYLAR 0.1uF 10% 100V
C889 1-164-159-11 CERAMIC 0.1uF 50V
C890 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN801 1-770-722-11 CONNECTOR, BOARD TO BOARD 6P
CN802 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-110-09 DIODE RD8.2ES-B3
D802 8-719-911-19 DIODE 1SS133T-72
D821 8-719-911-19 DIODE 1SS133T-72
D831 8-719-911-19 DIODE 1SS133T-72
D851 8-719-110-09 DIODE RD8.2ES-B3
D852 8-719-911-19 DIODE 1SS133T-72
D871 8-719-911-19 DIODE 1SS133T-72
D881 8-719-510-68 DIODE D5SBA20F101
D882 8-719-510-68 DIODE D5SBA20F101
D883 8-719-911-19 DIODE 1SS133T-72
D884 8-719-911-19 DIODE 1SS133T-72
D885 8-719-911-19 DIODE 1SS133T-72
< GROUND PLATE >
* EP801 1-537-738-21 TERMINAL, EARTH
* EP802 1-537-738-21 TERMINAL, EARTH
< IC >
IC801 8-749-016-11 IC STK411-230M
< COIL >
L801 1-420-872-00 COIL, AIR-CORE
L851 1-420-872-00 COIL, AIR-CORE
L871 1-420-872-00 COIL, AIR-CORE
L872 1-420-872-00 COIL, AIR-CORE
L873 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q821 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q822 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q825 8-729-620-05 TRANSISTOR 2SC2603-EF
Q826 8-729-620-05 TRANSISTOR 2SC2603-EF
Q827 8-729-620-05 TRANSISTOR 2SC2603-EF
Q828 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q829 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q830 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q832 8-729-620-05 TRANSISTOR 2SC2603-EF
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q881 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q882 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q883 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q884 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q885 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q886 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-249-416-11 CARBON 820 5% 1/4W F
R804 1-249-438-11 CARBON 56K 5% 1/4W
! R805 1-212-881-11 FUSIBLE 100 5% 1/4W F
R806 1-260-335-11 CARBON 3.9K 5% 1/2W
! R807 1-217-156-00 METAL 0.22 10% 5W
R808 1-249-417-11 CARBON 1K 5% 1/4W F
R809 1-249-431-11 CARBON 15K 5% 1/4W
R810 1-249-441-11 CARBON 100K 5% 1/4W
R811 1-260-076-11 CARBON 10 5% 1/2W
R812 1-260-076-11 CARBON 10 5% 1/2W
R813 1-260-076-11 CARBON 10 5% 1/2W
R814 1-249-437-11 CARBON 47K 5% 1/4W
R821 1-249-435-11 CARBON 33K 5% 1/4W
R822 1-249-433-11 CARBON 22K 5% 1/4W
R823 1-249-439-11 CARBON 68K 5% 1/4W
R824 1-249-421-11 CARBON 2.2K 5% 1/4W F
R825 1-249-433-11 CARBON 22K 5% 1/4W
R826 1-249-429-11 CARBON 10K 5% 1/4W
R827 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R828 1-202-972-61 FUSIBLE 1 5% 1/4W F
R832 1-249-431-11 CARBON 15K 5% 1/4W
R833 1-249-435-11 CARBON 33K 5% 1/4W
R835 1-249-425-11 CARBON 4.7K 5% 1/4W F
R836 1-249-425-11 CARBON 4.7K 5% 1/4W F
R837 1-249-433-11 CARBON 22K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
R839 1-249-429-11 CARBON 10K 5% 1/4W
R840 1-249-429-11 CARBON 10K 5% 1/4W
R841 1-249-437-11 CARBON 47K 5% 1/4W
R842 1-249-438-11 CARBON 56K 5% 1/4W
R843 1-249-439-11 CARBON 68K 5% 1/4W
R844 1-249-438-11 CARBON 56K 5% 1/4W
R845 1-249-437-11 CARBON 47K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-249-416-11 CARBON 820 5% 1/4W F
R854 1-249-438-11 CARBON 56K 5% 1/4W
! R855 1-212-881-11 FUSIBLE 100 5% 1/4W F
R856 1-260-335-11 CARBON 3.9K 5% 1/2W
! R857 1-217-156-00 METAL 0.22 10% 5W
R858 1-249-417-11 CARBON 1K 5% 1/4W F
R859 1-249-431-11 CARBON 15K 5% 1/4W
R860 1-249-441-11 CARBON 100K 5% 1/4W
R861 1-260-076-11 CARBON 10 5% 1/2W
R862 1-260-076-11 CARBON 10 5% 1/2W
R863 1-260-076-11 CARBON 10 5% 1/2W
R864 1-249-437-11 CARBON 47K 5% 1/4W
R871 1-249-437-11 CARBON 47K 5% 1/4W
R872 1-249-437-11 CARBON 47K 5% 1/4W
R873 1-249-437-11 CARBON 47K 5% 1/4W
R874 1-260-076-11 CARBON 10 5% 1/2W
R875 1-260-076-11 CARBON 10 5% 1/2W
R876 1-260-076-11 CARBON 10 5% 1/2W
FRONT AMP
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
To Next Page
