HVR-V1E/V1P
2-887-521-12(1)
A BATT RELEASE (battery release)
button (23)
B Hook for the shoulder strap (140)
C OPEN/EJECT lever (30)
D Grip belt (25)
E INPUT2 jack (20)
F INPUT1 jack (20)
G Lens (14)
H Lens hood with lens cover (21)
To attach the shoulder strap
Attach the shoulder strap (optional) to the
hooks for the shoulder strap.
1
3
5
2
4
7
8
6
Identifying parts and controls (Continued)
To Next Page
