132
KDL-26S3000/32S3000/40S3000/46S3000
KDL-26S3000/32S3000/40S3000/46S3000
VCC
OUT
GND
GP1UE26RK0VF
IC401
123
4
5
1608
50V
220p
B
C401
2012
6.3V
10
X6S
C402
1/10W
RN-CP
470
R401
5%
1/10W
RN-CP
47
R402
5%
1
2
3
3P
CN401
SIRCS
STBY3.3V
GND
H4 Sircs
CN3008
TO BU1
A-1220-320-A <WAX3>H4
H4 BOARD SCHEMATIC DIAGRAM
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8
A
—
B
—
C
—
D
—
E
—
F
—
G
—
H
—
