KDL-26S3000/32S3000/40S3000/46S3000
KDL-26S3000/32S3000/40S3000/46S3000
KDL-26S3000 ONLY
Route LVDS Cable as Shown
Put attention to the Cable (ABOVE or
BELOW) other cables.
Torque: 3mm Screw: 6kg-cm
OPERATION PROCESS
TORQUE SPECIFICATION
NOTE COLOR of the Ground Tabs (Gold)
Use 3x8mm screws to fix tabs.
NOTE:
LVDS Cable is dressed NEXT
to H3 wires w/Sheet Core C!
1
2
2
3
LVDS CABLE (CONTINUED)
To Next Page
