80
KDL-26S3000/32S3000/40S3000/46S3000
KDL-26S3000/32S3000/40S3000/46S3000
KDL-46S3000 ONLY
Install/Wire Dress Harnesses as shown.
CAUTION: Make sure INVERTER CONN.
is Fully LOCKED!!
OPERATION PROCESS
1
2
G3-
Bd
CAUTION: Make Sure
Inverter Connector is Fully LOCKED!
D1-
Bd
3
4
NOTE: Ferrite Core and Sheet Core A
Applied by SBC Plants.
3
5
1
6
G3 BOARD AND D1 BOARD
To Next Page
