— 40 —
67
Additional Information
Menu item Function Parameters Factory Page(s)
setting
Play/Pause Enables eject during playback Enable Enable 28
Z Disables eject during playback Disable 28
Next Tr Play Reserve the next track during play On/Off Off 30
Keyboard Selects the type of keyboard Type US US 55
JP 55
10-Key 55
Assigns characters to keyboard Assign? — 55
Edit Menu Table
The following table provides a quick guide to the various editing functions that can be performed.
To access the Edit Menu
Press MENU/NO to display “Edit Menu”
(Note : The available menu items may vary depending on the current status of the recorder.)
Menu item Sub item Function Reference page
Name? Nm In? Names track or MD 46
Nm Erase? Erases name 49
Nm AllErs? Erases all names 49
Nm Copy? Copies name 48
Nm AllCopy? Gives the same name to all tracks 48
Tr Erase? — Erases a track 41
Move? — Moves a track 44
Combine? — Combines tracks 43
Divide? — Divides a track 45
A-B Erase? — Erases a portion of a track 42
All Erase? — Erases all the tracks on an MD 42
M-Tr Erase? — Erases consecutive tracks at one time 42
M-Tr Combin? — Combines consecutive tracks at one time 43
S. F Edit? Tr Level? Changes the overall recorded level after recording 50
Fade In? Records over a track using Fade-in Recording 51
Fade Out? Records over a track using Fade-out Recording 51
Undo? — Undoes the last edit operation 50
Setup? — Enters Setup Menu —
Last Mode Memory
This function remembers the last mode of the recorder
after power was turned off. When the power is turned on
again, playback begins under the same conditions.
However, when the MD is ejected, the following functions
are not applied.
• Setting of Program track numbers and track order
• Setting of Multi-access track numbers and track order
• Setting of Variable Speed Play
• MARK point
• RAM edit contents
* Functions of the Setup Menu such as level, ON/OFF,
time, etc., will remain.
63
Additional Information
Display Messages
The following table explains the various messages that
appear in the display. Please also see the recorder’s Self
Diagnosis function on page 62.
Message Meaning
Auto Cut The Auto Cut function is on (page 22)
Blank Disc A new (blank) or erased MD has been
inserted.
Cannot Copy An attempt was made to make a
second copy from a digitally dubbed
MD.
Cannot Edit The MD is a commercially recorded
disc and cannot be edited.
An attempt was made to edit the MD
during Program or Shuffle Play.
An attempt was made to edit an MD
recorded in LP2 or LP4 stereo.
Disc Full The MD is full
Impossible The recorder cannot do the specified
operation.
Incomplete! The change of recording level or
Fade-In Fade-Out operations were
not properly made due to the
recorder being moved, damage to the
disc, dirt, etc.
Initialize (flashing) The Setup Menu settings have been
lost. Or the contents recorded by the
timer have disappeared over time
and are not available for saving to
disc, or the playback condition was
not stored the last time the recorder
was used. (When the power is turned
on, this flashes for about four
seconds).
Memorizing This flashes while the memory is
(flashing) storing the contents of editing using
Multi-access play to edit the track
order.
Name Full! The limitation on the number of
characters that can be input for
naming has been reached. A
maximum of approximately 1,700
characters can be input.
No Change While changing recording levels,
AMS or YES were pushed without
the level change being made, so that
no changes were recorded.
No Disc There is no MD in the recorder.
No Name The track or disc has no name.
No Program! An attempt was made to start
Program Play when no program
exists.
Premastered An attempt was made to record on a
premastered MD.
ProgramFull The program contains the maximum
number of tracks, and no more can be
added.
REMOTE The recorder is being controlled by a
connected external device.*
Message Meaning
S.F Edit! During S.F Edit (change of sound
level after recording, Fade-In, Fade-
Out), another operation was made.
During S.F Edit, no other operations
can be made.
Smart Space The Smart Space function is on (page
22).
TOC Reading After the insertion of the MD, the
recorder is reading the recorded
material.
M. Access The button for an operation which
cannot be made during Multi-access
play was pressed.
No Date DATE-RECORDED of the remote
was pressed with a track without the
time and date recorded present.
* If “REMOTE” appears under other circumstances, turn the recorder off,
then turn it on again.
66
Additional Information
Setup Menu Table
The following table provides an overview of the various Setup Menu items, including their parameters, factory setting, and
reference page (s) in the manual.
To access the Setup Menu
Press MENU/NO twice ; “Setup Menu” appears in the display.
(Note : The menu items available when MENU/NO is pressed may vary according to the current status of the recorder.)
Menu item Function Parameters Factory Page(s)
setting
Program? Creates a program ——33
M. Access? Creates a program ——34
Play Mode Selects Play Mode Continue Continue 27
Shuffle 32
Program 33
M. Access 34
Repeat Mode Selects repeat mode Repeat Off Off 31
Repeat All 31
Repeat 1 31
A-B Repeat 32
A. Cue Level Sets the level for detecting the start of track _72 to _48dB _72dB 38
A Cue Offset Adjusts the position of the start of auto-cue ±1 sec. 0 38
Music Scan Adjusts playback time of music scan 6 to 20 sec. 6 sec. 29
Mark Rehear Adjusts position of mark ——37
Direct Mark Mark poistion time is directly input ——36
Output Level Adjusts analog signal output level _20.2 to 0 dB 0dB 28
Input Level Coax Adjusts the level of the digital input _ ∞ to +18dB 0dB 21
signal from the COAXIAL terminal
Input Level OPT Adjusts the level of the input from _ ∞ to +18dB 0dB 21
the OPTICAL terminal
Input Level Anlg Adjust the level of the input from _ ∞ to +12dB 0dB 21
the ANALOG terminal
Anlg In L/R Adjust difference between left and right — 0dB 21
output of ANALOG signal
Rec Mode Selects recording mode Stereo Stereo 20
Mono 20
Long 2 20
Long 4 20
Smart Space Sets Smart Space and AutoCut On/Off On 22
Track Mark Sets track marking method Level Sync Level/Sync 23
Off 23
Interval 23
Tr Mark Level Sets base level for auto track marking _72 to _48dB _72dB 23
Interval Sets constant time interval of auto-track 1 to 10 min. 1 min. 23
marking
Peak Hold Indicates the highest level of the signal On/Off Off 21
End Of Tr/Disc Indicates time to end of track in playback, On/Off Off 53
end of disc in recording
EOT (Play) Sets time of indication of end of 6 to 20 sec. 6 sec. 53
track in playback
EOD (REC) Sets time of indication of end of 3 to 10 min. 3 min. 53
disc in recording
Resume Mode Turns off resume mode. Resume Off Resume Off 36
Play starts position of previous stop. Resume Play 36
Play starts next track of previous stop. Resume Next 36
Timer Turns off timer function. Off Off 54
Starts playback when power is turned on. Play 54
Starts recording when power is turned on. Rec 54
To Next Page
