— 100 —
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C145 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C146 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C147 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C151 1-117-370-11 CERAMIC CHIP 10uF 10V
C152 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C153 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C154 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C155 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C156 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C157 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C158 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C159 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C160 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C161 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C162 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C163 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C164 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C165 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C166 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C167 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
C169 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C171 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C172 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C180 1-117-370-11 CERAMIC CHIP 10uF 10V
C181 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C182 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C183 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C184 1-117-970-11 ELECT CHIP 22uF 20.00% 10V
C185 1-131-872-91 CERAMIC CHIP 1000PF 10% 630V
C191 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C192 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C193 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C194 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C195 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C196 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1401 1-117-720-11 CERAMIC CHIP 4.7uF 10V
< CONNECTOR >
CN101 1-766-833-21 CONNECTOR, FFC/FPC (ZIF) 21P
CN102 1-784-835-21 CONNECTOR,FFC(LIF(NON-ZIF))27P
CN103 1-784-834-21 CONNECTOR,FFC(LIF(NON-ZIF))23P
* CN104 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN105 1-784-859-21 CONNECTOR, FFC(LIF(NON-ZIF))7P
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D181 8-719-080-81 DIODE FS1J6
D183 8-719-080-81 DIODE FS1J6
< IC >
IC101 8-752-080-95 IC CXA2523AR
IC102 8-759-473-51 IC TLV2361CDBV
IC141 8-759-430-25 IC BH6511FS-E2
IC151 8-752-404-64 IC CXD2662R
IC152 8-759-599-51 IC MSM51V17400D-50TS-K
IC171 8-759-096-87 IC TC7WU04FU(TE12R)
IC181 8-759-481-17 IC MC74ACT08DTR2
IC190 8-759-460-72 IC BA033FP-E2
IC195 8-759-640-41 IC BR24C08F-E2
< JUMPER RESISTOR >
JW201 1-216-295-91 SHORT 0
JW202 1-216-295-91 SHORT 0
JW203 1-216-295-91 SHORT 0
JW903 1-216-295-91 SHORT 0
JW904 1-216-295-91 SHORT 0
< COIL >
L101 1-500-245-11 INDUCTOR CHIP 0uH
L102 1-500-245-11 INDUCTOR CHIP 0uH
L103 1-500-245-11 INDUCTOR CHIP 0uH
L105 1-414-235-22 INDUCTOR CHIP 0uH
L106 1-500-245-11 INDUCTOR CHIP 0uH
L121 1-500-245-11 INDUCTOR CHIP 0uH
L122 1-500-245-11 INDUCTOR CHIP 0uH
L131 1-500-245-11 INDUCTOR CHIP 0uH
L141 1-412-029-11 INDUCTOR CHIP 10uH
L142 1-412-032-11 INDUCTOR CHIP 100uH
L143 1-412-029-11 INDUCTOR CHIP 10uH
L144 1-412-032-11 INDUCTOR CHIP 100uH
L145 1-412-032-11 INDUCTOR CHIP 100uH
L146 1-469-855-21 INDUCTOR 0uH
L147 1-469-855-21 INDUCTOR 0uH
L161 1-500-245-11 INDUCTOR CHIP 0uH
L171 1-500-245-11 INDUCTOR CHIP 0uH
L180 1-469-855-21 INDUCTOR 0uH
L181 1-469-855-21 INDUCTOR 0uH
L182 1-500-245-11 INDUCTOR CHIP 0uH
L183 1-216-296-91 SHORT 0
L184 1-216-296-91 SHORT 0
< TRANSISTOR >
Q101 8-729-403-35 TRANSISTOR UN5113-TX
Q121 8-729-403-35 TRANSISTOR UN5113-TX
Q122 8-729-101-07 TRANSISTOR 2SB798-T1DK
Q131 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q132 8-729-903-10 TRANSISTOR FMW1-T-148
Q133 8-729-402-93 TRANSISTOR UN5214-TX
Q134 8-729-402-93 TRANSISTOR UN5214-TX
Q181 8-729-018-75 TRANSISTOR 2SJ278MYTR
Q182 8-729-017-65 TRANSISTOR 2SK1764KYTR
< RESISTOR >
R101 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R102 1-216-853-11 METAL CHIP 470K 5% 1/16W
R103 1-216-863-11 RES-CHIP 3.3M 5% 1/16W
R104 1-216-853-11 METAL CHIP 470K 5% 1/16W
R105 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R107 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R108 1-216-833-91 RES-CHIP 10K 5% 1/16W
R109 1-216-845-11 METAL CHIP 100K 5% 1/16W
R110 1-216-845-11 METAL CHIP 100K 5% 1/16W
R111 1-216-833-91 RES-CHIP 10K 5% 1/16W
R112 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R113 1-216-833-91 RES-CHIP 10K 5% 1/16W
R114 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R115 1-216-833-91 RES-CHIP 10K 5% 1/16W
