— 101 —
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R116 1-216-839-11 METAL CHIP 33K 5% 1/16W
R117 1-216-837-11 METAL CHIP 22K 5% 1/16W
R118 1-218-855-11 METAL CHIP 2.2K 0.5% 1/16W
R119 1-218-863-11 METAL CHIP 4.7K 0.5% 1/16W
R120 1-218-889-11 METAL CHIP 56K 0.5% 1/16W
R121 1-218-863-11 METAL CHIP 4.7K 0.5% 1/16W
R122 1-218-855-11 METAL CHIP 2.2K 0.5% 1/16W
R123 1-216-819-11 METAL CHIP 680 5% 1/16W
R124 1-216-809-11 METAL CHIP 100 5% 1/16W
R125 1-216-815-11 METAL CHIP 330 5% 1/16W
R126 1-216-819-11 METAL CHIP 680 5% 1/16W
R127 1-216-845-11 METAL CHIP 100K 5% 1/16W
R128 1-219-724-11 METAL CHIP 1 1% 1/4W
R129 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R130 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R131 1-216-833-91 RES-CHIP 10K 5% 1/16W
R132 1-216-841-11 METAL CHIP 47K 5% 1/16W
R133 1-216-821-11 METAL CHIP 1K 5% 1/16W
R134 1-216-821-11 METAL CHIP 1K 5% 1/16W
R135 1-216-821-11 METAL CHIP 1K 5% 1/16W
R136 1-216-295-91 SHORT 0
R138 1-216-833-91 RES-CHIP 10K 5% 1/16W
R150 1-216-833-91 RES-CHIP 10K 5% 1/16W
R151 1-216-833-91 RES-CHIP 10K 5% 1/16W
R154 1-216-833-91 RES-CHIP 10K 5% 1/16W
R155 1-216-864-11 METAL CHIP 0 5% 1/16W
R156 1-216-864-11 METAL CHIP 0 5% 1/16W
R157 1-216-809-11 METAL CHIP 100 5% 1/16W
R158 1-216-809-11 METAL CHIP 100 5% 1/16W
R159 1-216-833-91 RES-CHIP 10K 5% 1/16W
R160 1-216-833-91 RES-CHIP 10K 5% 1/16W
R161 1-216-833-91 RES-CHIP 10K 5% 1/16W
R163 1-216-809-11 METAL CHIP 100 5% 1/16W
R164 1-216-809-11 METAL CHIP 100 5% 1/16W
R165 1-216-809-11 METAL CHIP 100 5% 1/16W
R167 1-216-833-91 RES-CHIP 10K 5% 1/16W
R168 1-216-845-11 METAL CHIP 100K 5% 1/16W
R169 1-216-855-11 METAL CHIP 680K 5% 1/16W
R170 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R171 1-216-821-11 METAL CHIP 1K 5% 1/16W
R173 1-216-821-11 METAL CHIP 1K 5% 1/16W
R174 1-216-811-11 METAL CHIP 150 5% 1/16W
R175 1-216-857-11 METAL CHIP 1M 5% 1/16W
R176 1-216-809-11 METAL CHIP 100 5% 1/16W
R179 1-216-295-91 SHORT 0
R181 1-216-841-11 METAL CHIP 47K 5% 1/16W
R182 1-216-841-11 METAL CHIP 47K 5% 1/16W
R183 1-216-841-11 METAL CHIP 47K 5% 1/16W
R184 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R185 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R195 1-216-833-91 RES-CHIP 10K 5% 1/16W
R196 1-216-833-91 RES-CHIP 10K 5% 1/16W
R197 1-216-833-91 RES-CHIP 10K 5% 1/16W
R218 1-216-864-11 METAL CHIP 0 5% 1/16W
< SWITCH >
S101 1-762-596-21 SWITCH, PUSH (1 KEY)(LIMIT IN)
S103 1-771-956-21 SWITCH, PUSH (1 KEY)(OUT)
S104 1-771-955-21 SWITCH, PUSH (1 KEY)(PLAY)
S105 1-771-955-21 SWITCH, PUSH (1 KEY)(REC)
**************************************************************
* A-4591-313-A FL BOARD, COMPLETE
*******************
< CAPACITOR >
C720 1-124-589-11 ELECT 47uF 20% 16V
C722 1-124-589-11 ELECT 47uF 20% 16V
C723 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN720 1-566-969-11 HOUSING, CONNECTOR (PC BOARD) 7P
CN721 1-815-144-11 PIN, CONNECTOR 8P (PC BOARD)
CN722 1-779-560-21 CONNECTOR,FFC (LIF(NON-ZIF)) 23P
< DIODE >
D720 8-719-109-97 DIODE RD6.8ES-B2
D721 8-719-109-97 DIODE RD6.8ES-B2
< INDICATOR >
FLK720 1-518-714-12 INDICATOR TUBE, FLUORESCENT
< RESISTOR >
R760 1-249-425-11 CARBON 4.7K 5% 1/4W F
R761 1-247-843-11 CARBON 3.3K 5% 1/4W
R762 1-249-421-11 CARBON 2.2K 5% 1/4W F
R763 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S720 1-762-875-21 SWITCH, KEYBOARD (VARI SPEED)
S721 1-762-875-21 SWITCH, KEYBOARD (+)
S722 1-762-875-21 SWITCH, KEYBOARD (-)
S723 1-762-875-21 SWITCH, KEYBOARD (EJECT)
******************************************************************
* A-4591-310-A HP BOARD, COMPLETE
*******************
< CAPACITOR >
C730 1-162-294-31 CERAMIC 0.001uF 10% 50V
C731 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CN730 1-564-506-11 PLUG, CONNECTOR 3P
< JACK >
J730 1-770-904-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R730 1-249-393-11 CARBON 10 5% 1/4W F
R731 1-249-393-11 CARBON 10 5% 1/4W F
< VARIABLE RESISTOR >
RV730 1-225-302-11 RES, VAR, CARBON 1K/1K (PHONE LEVEL)
******************************************************************
FL HPBD
