— 102 —
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
* A-4591-312-A KEY BOARD, COMPLETE
********************
< CAPACITOR >
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-794-928-11 PIN, CONNECTOR 7P (PC BOARD)
< FERRITE BEAD >
FB701 1-410-397-21 FERRITE BEAD INDUCTOR
FB702 1-410-397-21 FERRITE BEAD INDUCTOR
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-429-11 CARBON 10K 5% 1/4W
R703 1-249-421-11 CARBON 2.2K 5% 1/4W F
R704 1-249-421-11 CARBON 2.2K 5% 1/4W F
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-247-843-11 CARBON 3.3K 5% 1/4W
R707 1-247-843-11 CARBON 3.3K 5% 1/4W
R708 1-249-425-11 CARBON 4.7K 5% 1/4W F
R709 1-249-421-11 CARBON 2.2K 5% 1/4W F
R710 1-247-843-11 CARBON 3.3K 5% 1/4W
R711 1-249-425-11 CARBON 4.7K 5% 1/4W F
R712 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S700 1-473-779-11 ENCODER, ROTARY (AMS)
S701 1-762-875-21 SWITCH, KEYBOARD (CLEAR)
S702 1-762-875-21 SWITCH, KEYBOARD (PLAY/PAUSE)
S703 1-762-875-21 SWITCH, KEYBOARD (STOP)
S704 1-762-875-21 SWITCH, KEYBOARD (REC)
S705 1-762-875-21 SWITCH, KEYBOARD (LEVEL)
S706 1-762-875-21 SWITCH, KEYBOARD (TIME)
S707 1-762-875-21 SWITCH, KEYBOARD (LOCATE)
S708 1-762-875-21 SWITCH, KEYBOARD (AUTO CUE)
S709 1-762-875-21 SWITCH, KEYBOARD (EDIT/NO)
S710 1-762-875-21 SWITCH, KEYBOARD (YES)
S711 1-762-875-21 SWITCH, KEYBOARD (REW)
S712 1-762-875-21 SWITCH, KEYBOARD (FF)
******************************************************************
* A-4591-321-A MAIN BOARD, COMPLETE (J)
************************
* A-4591-322-A MAIN BOARD, COMPLETE (AEP,E)
***************************
* A-4591-323-A MAIN BOARD, COMPLETE (US,CND)
*****************************
2-347-238-01 BRACKET (VS)
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
< BATTERY >
BT100 1-528-887-11 BATTERY, LITHIUM SECONDARY
< CAPACITOR >
C102 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C103 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C104 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C105 1-119-932-11 ELECT (BLOCK) 22000uF 20.00% 16V
C107 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C108 1-126-767-11 ELECT 1000uF 20.00% 16V
C109 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C110 1-104-665-11 ELECT 100uF 20.00% 25V
C111 1-104-665-11 ELECT 100uF 20.00% 25V
C112 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C113 1-119-800-11 ELECT 100uF 20.00% 25V
C114 1-119-803-31 ELECT 470uF 20.00% 25V
C115 1-128-555-91 ELECT 470uF 20.00% 63V
C116 1-126-964-11 ELECT 10uF 20.00% 50V
C117 1-126-964-11 ELECT 10uF 20.00% 50V
C118 1-119-800-11 ELECT 100uF 20.00% 25V
C119 1-119-800-11 ELECT 100uF 20.00% 25V
C120 1-119-793-11 ELECT 1000uF 20.00% 16V
C121 1-119-793-11 ELECT 1000uF 20.00% 16V
C124 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C125 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C126 1-104-665-11 ELECT 100uF 20.00% 10V
C127 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C129 1-126-963-11 ELECT 4.7uF 20.00% 50V
C131 1-126-963-11 ELECT 4.7uF 20.00% 50V
C132 1-104-656-11 ELECT 2200uF 20.00% 6.3V
C133 1-126-926-11 ELECT 1000uF 20.00% 10V
C134 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C135 1-126-937-11 ELECT 4700uF 20.00% 16V
C136 1-126-933-11 ELECT 100uF 20.00% 16V
C137 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C140 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C200 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C201 1-126-926-11 ELECT 1000uF 20.00% 10V
C202 1-163-222-11 CERAMIC CHIP 5PF 0.25PF 50V
C203 1-163-222-11 CERAMIC CHIP 5PF 0.25PF 50V
C210 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C211 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C212 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C213 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C214 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C215 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C216 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C217 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C218 1-119-792-21 ELECT 470uF 20.00% 16V
C219 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C220 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C221 1-119-792-21 ELECT 470uF 20.00% 16V
C222 1-107-611-11 CAPACITOR 100PF 5.00% 500V
C223 1-107-611-11 CAPACITOR 100PF 5.00% 500V
C224 1-130-479-00 MYLAR 0.0047uF 5% 50V
C225 1-130-471-00 MYLAR 0.001uF 5% 50V
C226 1-126-022-11 ELECT 47uF 20.00% 25V
C227 1-130-467-00 MYLAR 470PF 5% 50V
C228 1-109-621-00 MICA 220PF 1% 500V
KEY MAIN
