— 10 —
3-4.
B
ASE UNIT
1
Leaf spring (UDL)
2
Leaf spring (UDR)
3
Holder assemb
ly
5
Base unit
(MBU-2B)
4
Three screws
(BVTP 3x6)
3-5.
HMO
T BO
ARD AND HLIM BO
ARD
5
Stopper washer
6
Gear (HEAD C)
8
Gear (HEAD B)
9
T
wo screws
(Precision P2x3)
1
Stopper
washer
3
Lev
er (OWH)
4
T
orsion spr
ing (O
WH)
2
Shaft (O
WH)
!™
HLIM board
!¡
T
wo screws
(PTP 2.6x6)
7
Stopper washer
!º
HMO
T board
9
11
