— 77 —
#14
#14
#6
#14
#6
#15#15
#15
#6
#6
310
306
311
309
308
not
supplied
304
305
302
302
303
301
not supplied
307
* 301 4-987-291-01 BRACKET (TOP)
302 4-987-293-01 GEAR (4)
303 X-4948-835-1 SLIDER (D) ASSY
* 304 4-987-267-01 TABLE (EJECT)
* 305 4-987-282-01 TRAY
306 4-987-270-01 STOPPER (SHAFT A)
307 4-993-436-01 SHAFT
* 308 4-987-294-01 GUIDE (SHAFT)
309 4-987-271-01 STOPPER (SHAFT B)
310 4-987-269-01 RACK (L)
311 4-987-268-01 RACK (R)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
7-5. MECHANISM SECTION 1 (MDM-4B)
To Next Page
