Note:
• Due to standardization, replacements in the
par ts list ma y be different from the par ts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
ha ve some diff erence from the or iginal one .
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESIST ORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCT ORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 81 —
• Abbreviation
G : German
* 1-666-751-11 AC BOARD
********
< CAPACITOR >
! C001 1-113-920-11 CERAMIC 0.0022uF 20% 250V
(AEP,UK,G)
! C002 1-113-920-11 CERAMIC 0.0022uF 20% 250V
! C003 1-113-920-11 CERAMIC 0.0022uF 20% 250V
! C004 1-113-920-11 CERAMIC 0.0022uF 20% 250V
! C005 1-113-925-11 CERAMIC 0.01uF 20% 250V
! C006 1-113-925-11 CERAMIC 0.01uF 20% 250V
! C007 1-113-925-11 CERAMIC 0.01uF 20% 250V
(AEP,UK,G)
< CONNECTOR >
CN002 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN004 1-564-321-00 PIN, CONNECTOR 2P
< GROUND >
* EP001 4-870-539-00 PLATE, GROUND
< LINE FILTER >
! LF001 1-424-485-11 FILTER, LINE
< SWITCH >
! S001 1-762-764-11 SWITCH, POWER (AEP,UK,G)
************************************************************
* A-4699-789-A AD BOARD, COMPLETE
*******************
< CAPACITOR >
C305 1-162-294-31 CERAMIC 0.001uF 10% 50V
C307 1-164-159-11 CERAMIC 0.1uF 50V
C308 1-164-159-11 CERAMIC 0.1uF 50V
C309 1-124-994-11 ELECT 100uF 20% 10V
C310 1-164-159-11 CERAMIC 0.1uF 50V
C312 1-136-169-00 FILM 0.22uF 5% 50V
C313 1-126-048-81 ELECT 10uF 20% 50V
C315 1-124-995-11 ELECT 220uF 20% 10V
C317 1-164-159-11 CERAMIC 0.1uF 50V
C320 1-136-816-11 FILM 0.0022uF 5% 100V
C321 1-136-816-11 FILM 0.0022uF 5% 100V
C322 1-164-159-11 CERAMIC 0.1uF 50V
C325 1-126-023-11 ELECT 100uF 20% 25V
C326 1-126-023-11 ELECT 100uF 20% 25V
C327 1-126-023-11 ELECT 100uF 20% 25V
SECTION 8
ELECTRICAL PARTS LIST
AC AD
C328 1-126-023-11 ELECT 100uF 20% 25V
C329 1-126-023-11 ELECT 100uF 20% 25V
C330 1-126-023-11 ELECT 100uF 20% 25V
C331 1-164-159-11 CERAMIC 0.1uF 50V
C333 1-126-023-11 ELECT 100uF 20% 25V
C334 1-126-023-11 ELECT 100uF 20% 25V
C335 1-126-023-11 ELECT 100uF 20% 25V
C336 1-126-023-11 ELECT 100uF 20% 25V
C337 1-126-022-11 ELECT 47uF 20% 10V
< CONNECTOR >
CN301 1-580-463-11 SOCKET, CONNECTOR 16P
* CN302 1-564-509-11 PLUG, CONNECTOR 6P
CN303 1-564-511-11 PLUG, CONNECTOR 8P
* CN304 1-564-508-11 PLUG, CONNECTOR 5P
< DIODE >
D301 8-719-987-63 DIODE 1N4148M
D302 8-719-987-63 DIODE 1N4148M
D303 8-719-987-63 DIODE 1N4148M
D304 8-719-987-63 DIODE 1N4148M
D305 8-719-987-63 DIODE 1N4148M
D306 8-719-987-63 DIODE 1N4148M
D307 8-719-987-63 DIODE 1N4148M
D308 8-719-987-63 DIODE 1N4148M
D309 8-719-210-21 DIODE 11EQS04
D310 8-719-210-21 DIODE 11EQS04
< GROUND >
* EP301 4-870-539-00 PLATE, GROUND
< IC >
IC301 8-759-604-35 IC M5F78M05L
IC302 8-759-462-08 IC AK5352-VF-E2
IC303 8-759-712-02 IC NJM2114D
IC304 8-759-712-02 IC NJM2114D
IC305 8-759-712-02 IC NJM2114D
IC306 8-759-712-02 IC NJM2114D
< COIL >
L301 1-408-405-00 INDUCTOR 4.7uH
< RESISTOR >
R301 1-259-404-11 CARBON 100 5% 1/6W
R302 1-259-380-11 CARBON 10 5% 1/6W
R303 1-259-380-11 CARBON 10 5% 1/6W
R304 1-259-380-11 CARBON 10 5% 1/6W
R305 1-259-380-11 CARBON 10 5% 1/6W
To Next Page
