Sony MDS-JA30ES Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 83 —
< DIODE >
D101 8-719-988-62 DIODE 1SS355
D155 8-719-031-17 DIODE 1SS322-TE85L
D161 8-719-421-15 DIODE MA8027-L
D181 8-719-033-60 DIODE F1P2STP
D183 8-719-033-60 DIODE F1P2STP
< IC >
IC101 8-752-072-68 IC CXA1981AR
IC102 8-759-243-19 IC TC7SU04F
IC121 8-752-378-79 IC CXD2535CR
IC122 8-759-243-19 IC TC7SU04F
IC151 8-759-179-60 IC MPC17A38VMEL
IC171 8-759-504-12 IC X24C01S
IC172 8-759-149-73 IC uPC842G2
IC181 8-759-095-65 IC TC74ACT540FS
IC182 8-759-243-19 IC TC7SU04F
IC191 8-759-822-99 IC L88MS05T-FA
< COIL >
L101 1-414-234-11 INDUCTOR, FERRITE BEAD
L102 1-414-234-11 INDUCTOR, FERRITE BEAD
L103 1-414-234-11 INDUCTOR, FERRITE BEAD
L105 1-414-234-11 INDUCTOR, FERRITE BEAD
L106 1-414-234-11 INDUCTOR, FERRITE BEAD
L121 1-414-234-11 INDUCTOR, FERRITE BEAD
L122 1-412-039-51 INDUCTOR CHIP 100uH
L151 1-412-622-51 INDUCTOR 10uH
L152 1-412-622-51 INDUCTOR 10uH
L153 1-412-039-51 INDUCTOR CHIP 100uH
L154 1-412-039-51 INDUCTOR CHIP 100uH
L155 1-410-980-51 INDUCTOR CHIP 1mH
L161 1-414-234-11 INDUCTOR, FERRITE BEAD
L162 1-414-234-11 INDUCTOR, FERRITE BEAD
L195 1-233-316-21 FILTER, CHIP EMI
< MOTOR >
M101 A-4660-651-A MOTOR (SLED) ASSY
M102 A-4660-650-A CHASSIS ASSY, BU (SPINDLE)
< TRANSISTOR >
Q101 8-729-905-12 TRANSISTOR DTA144EU
Q151 8-729-905-18 TRANSISTOR DTC144EU
Q162 8-729-101-07 TRANSISTOR 2SB798-DL
Q163 8-729-905-12 TRANSISTOR DTA144EU
Q164 8-729-924-19 TRANSISTOR DTA123JU
Q181 8-729-018-75 TRANSISTOR 2SJ278MY
Q182 8-729-017-65 TRANSISTOR 2SK1764KY
< RESISTOR >
R101 1-216-077-00 METAL CHIP 15K 5% 1/10W
R102 1-216-073-00 METAL CHIP 10K 5% 1/10W
R103 1-216-073-00 METAL CHIP 10K 5% 1/10W
R104 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R105 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R106 1-216-133-00 METAL CHIP 3.3M 5% 1/10W
R107 1-216-113-00 METAL CHIP 470K 5% 1/10W
R110 1-216-077-00 METAL CHIP 15K 5% 1/10W
R113 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R114 1-216-025-91 METAL GLAZE 100 5% 1/10W
R116 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R117 1-216-113-00 METAL CHIP 470K 5% 1/10W
R120 1-216-025-91 METAL GLAZE 100 5% 1/10W
R121 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R122 1-216-295-91 CONDUCTOR, CHIP (2012)
R123 1-216-037-00 METAL CHIP 330 5% 1/10W
R124 1-216-025-91 METAL GLAZE 100 5% 1/10W
R125 1-216-025-91 METAL GLAZE 100 5% 1/10W
R128 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R129 1-216-037-00 METAL CHIP 330 5% 1/10W
R130 1-216-041-00 METAL CHIP 470 5% 1/10W
R131 1-216-073-00 METAL CHIP 10K 5% 1/10W
R132 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R133 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R134 1-216-037-00 METAL CHIP 330 5% 1/10W
R135 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R136 1-216-041-00 METAL CHIP 470 5% 1/10W
R137 1-216-025-91 METAL GLAZE 100 5% 1/10W
R139 1-216-017-91 METAL GLAZE 47 5% 1/10W
R140 1-216-017-91 METAL GLAZE 47 5% 1/10W
R141 1-216-295-91 CONDUCTOR, CHIP (2012)
R142 1-216-073-00 METAL CHIP 10K 5% 1/10W
R143 1-216-073-00 METAL CHIP 10K 5% 1/10W
R144 1-216-025-91 METAL GLAZE 100 5% 1/10W
R145 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R146 1-216-037-00 METAL CHIP 330 5% 1/10W
R147 1-216-025-91 METAL GLAZE 100 5% 1/10W
R148 1-216-045-00 METAL CHIP 680 5% 1/10W
R150 1-216-295-91 CONDUCTOR, CHIP (2012)
R151 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R154 1-220-262-11 METAL GLAZE 680 5% 1/4W
R155 1-220-262-11 METAL GLAZE 680 5% 1/4W
R158 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R161 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R162 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R163 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R164 1-216-045-00 METAL CHIP 680 5% 1/10W
R165 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R166 1-220-250-11 METAL GLAZE 10 5% 1/2W
R167 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R169 1-219-724-11 METAL CHIP 1 1% 1/4W
R170 1-216-073-00 METAL CHIP 10K 5% 1/10W
R171 1-216-073-00 METAL CHIP 10K 5% 1/10W
R172 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R174 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R176 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R178 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R181 1-216-073-00 METAL CHIP 10K 5% 1/10W
R182 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R183 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R186 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R187 1-216-134-00 METAL CHIP 2.2 5% 1/8W
< VARIABLE RESISTOR >
RV101 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV102 1-241-396-11 RES, ADJ, METAL GLAZE 22K
< SWITCH >
S101 1-572-467-61 SWITCH, PUSH (1 KEY)(LIMIT IN)
************************************************************
