67
Pin No.
43
44
45
46
47
48
49
50
51
52, 53
54
55
56
57
58
59
60
I/O
—
I
I
—
I
I
O
O
—
—
I
—
I
O
—
O
O
Description
Not used in this system (Blank terminal)
Input terminal to set the low-cut function. “L: OFF, “H”: ON. (Fixed at “H”)
Input terminal to set the noise shaving function. “L: OFF, “H”: ON. (Fixed at “H”)
Not used in this system. (Blank terminal)
Input pin for setting output sampling frequency
“L”: FS, “H”: 2FS (Fixed at “L” in this system)
Input terminal to set the output data word length. “L: 16 bit, “H”: 24 bits. (Fixed at “H”)
Data output during the 8FS and 2FS modes. WCK output during FS mode.
Not used in this system. (Blank terminal)
Recording data output to CXD2656R (IC121) of the MD mechanism deck
Not used in this system (Blank terminal)
Ground
Bit clock signal input (2.8224 MHz) from MD mechanism deck block CXD2656R (IC121)
Not used in this system (Blank terminal)
L/R sampling clock signal input (44.1 kHz) from MD mechanism deck block CXD2656R (IC121)
Sync flag output terminal of output side. Not used in this system (Blank terminal)
Power supply (+5 V)
Overflow flag output of R channel. Not used in this system (Blank terminal)
Overflow flag output of L channel. Not used in this system (Blank terminal)
Pin Name
NC
LC
NS
NC
OSEL
OBIT
DRO
DLO
NC
VSS
BCK
NC
LRCK
OFLG
VDD
OVR
OVL
To Next Page
