Sony MHC-V42D - Side Panel (L), (R)

MHC-V42D
11
Note: Followthedisassemblyprocedureinthenumericalordergiven.
2-2. SIDE PANEL (L), (R)
1 five screws
(+BVTP 3 × 8) (BLACK)
2 Remove the panel, side (R)
in the direction of the arrow.
2 Remove the panel, side (L)
in the direction of the arrow.
1 five screws
(+BVTP 3 × 8) (BLACK)
panel, side (L)
panel, side (R)
3
3
