Sony MHC-V42D Service Manual

56
MHC-V42D
SECTION 8
ELECTRICAL PARTS LIST
A-2225-350-A FL PARTY MOUNTED PC BOARD
**************************
*************************************************************
A-2225-349-A FR PARTY MOUNTED PC BOARD
**************************
*************************************************************
A-2225-347-A GESTURE MOUNTED PC BOARD
**************************
*************************************************************
A-2225-550-A IR MOUNTED PC BOARD
********************
*************************************************************
A-2225-345-A MIC MOUNTED PC BOARD
(AR, TH, E12, LA9)
A-5005-461-A MIC MOUNTED PC BOARD (EMC)
(AEP, UK, RU, MY, AUS, E4, E93)
**************************
*************************************************************
9 A-2228-423-A MOTHERBOARD MOUNTED PC BOARD
(for SERVICE) (EXCEPT AEP, UK)
9 A-2228-427-A MOTHERBOARD MOUNTED PC BOARD
(for SERVICE) (AEP, UK)
*******************************
< IC >
IC2001 6-723-247-01 IC TAS5534DGGR-S
IC2002 6-723-793-01 IC TAS5634
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, exchange the entire CDM90 ASSY.
*************************************************************
A-2194-756-A NFC MOUNT
**********
*************************************************************
A-2225-344-A PANEL MOUNTED PC BOARD
(EXCEPT MY, E12)
A-5001-942-A PANEL MOUNTED PC BOARD (PANA)
(MY, E12)
*****************************
*************************************************************
0 A-2226-524-A SMPS MOUNTED PC BOARD
(AR, TH, E12, LA9)
0 A-2228-975-A SMPS MOUNTED PC BOARD (EMC)
(AEP, UK, RU, MY, AUS, E4, E93)
****************************
*************************************************************
A-2225-351-A SW LED MOUNTED PC BOARD
************************
*************************************************************
MISCELLANEOUS
**************
53 1-912-918-11 FLEXIBLE FLAT CABLE (15 CORE)
55 1-912-998-11 FLEXIBLE FLAT CABLE (9 CORE)
56 1-912-921-11 FLEXIBLE FLAT CABLE (7 CORE)
62 1-972-246-11 FLEXIBLE FLAT CABLE (6 CORE)
0 153 1-855-006-41 FAN, DC
401 A-1937-669-D CDM90 ASSY (including MS-476 board)
0 404 A-2046-956-A SERVICE, OPTICAL DEVICE (7G)
406 1-972-245-11 FLEXIBLE FLAT CABLE (24 CORE)
407 1-912-919-11 FLEXIBLE FLAT CABLE (5 CORE)
SP1 1-859-316-11 LOUDSPEAKER 8CM (Mid: L-CH)
SP2 1-859-317-11 LOUDSPEAKER (4CM) (Tweeter: L-CH)
SP3 1-859-316-11 LOUDSPEAKER 8CM (Mid: R-CH)
SP4 1-859-317-11 LOUDSPEAKER (4CM) (Tweeter: R-CH)
SP5 1-859-315-11 LOUDSPEAKER 25CM (Woofer)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• Due to standardization, replacements in
the parts list may be different from the
partsspeciedinthediagramsorthecom-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
 METAL:Metal-lmresistor.
 METALOXIDE:Metaloxide-lmresistor.
 F:nonammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
 Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
 Ineachcase,u:µ,forexample:
 uA.. :µA..,uPA..,µPA..,
 uPB.. :µPB..,uPC..,µPC..,
 uPD.. :µPD..
• CAPACITORS
 uF:µF
• COILS
 uH:µH
IR
MOTHERBOARD
When indicating parts by reference num-
ber,pleaseincludetheboardname.
GESTURE
FL PARTY
NFC
Note 1: When the MOTHERBOARD board is replaced, spread
thecompoundreferringto“NOTEOFREPLACINGTHE
IC2002 ON THE MOTHERBOARD BOARD AND THE
MOTHERBOARD MOUNTED PC BOARD” on servicing
notes (page 6).
Note 2: WhenthecompleteMOTHERBOARDboardisreplaced,
besuretoreferto“DESTINATIONSETTINGMETHOD”
on page 5.
The components identied by mark 0
or dotted line with mark 0 are critical for
safety.
Replaceonlywithpartnumberspecied.
Thecomponentsidentiedbymark9 con-
taincondentialinformation.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Note 3: Ifexibleatcableisreplaced,installitafterbendingitin
thesameformasthatbeforereplacement.
SMPS
SMPS (EMC)
PANEL
PANEL (PANA)
FR PARTY
MS-476
MIC
SW LED
MIC (EMC)
SYSSET
2019/03/0500:47:46(GMT+09:00)
