Sony MHC-V42D - Rear Panel

MHC-V42D
16
2-7. REAR PANEL
1 CN2001 (2P)
2 four screws
(3.5 × 14), TAPPING
4 cap, service connector
3 one screw
(+BVTP 3 × 8) (BLACK)
5 seven screws
(+BVTP 3 × 8) (BLACK)
6 Remove the panel, rear section
in the direction of the arrow.
7 panel, rear section
