Sony MHC-V42D - Loading Panel Section

49
MHC-V42D
7-3. LOADING PANEL SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101 4-726-162-01 PANEL, LOADING
102 4-536-754-01 SPRING (LP)
103 4-588-651-01 LOADING, BASE
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
ns not supplied
102
ns
ns
ns
ns
ns
#1
CDM section
rear panel section
#2
101
103
SYSSET
