Sony MHC-V42D Service Manual

MHC-V42D
REVISION HISTORY
How to search for a contact point of signal lines or the like in DIAGRAMS SECTION
IfacontactpointofaBLOCKDIAGRAM,PRINTEDWIRINGBOARDorSCHEMATICDIAGRAMisshowninadifferentpage,use
thePDFlesearchfunctiontondone.
e.g.) If a contact point is shown as , follow the procedure below.
Procedure:
1. Press the [F] key while pressing the [Ctrl] key.
2. Input “>001Z” in the search box and press the [Enter] key.
3. The relevant part (page), where the contact point is shown, appears.
Note: If you still see the original page, press the [Enter] key again.
Ver. Date Description of Revision
1.0 2019.02 New
SYSSET
2019/03/0500:47:46(GMT+09:00)

Sony MHC-V42D Specifications

General

Speaker type	-
Speaker placement	Floor
Built-in amplifier	Yes
Number of woofer drivers	1
Number of tweeter drivers	2
Type	Home audio mini system
Control type	Buttons, Rotary
Cassette deck	No
Product color	Black
Disc loading type	Tray
Number of optical discs	1 discs
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Quantity per pack	1 pc(s)
RMS rated power	- W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Mid-range driver diameter	80 mm
Coloration	Monochromatic
Bluetooth profiles	A2DP, AVRCP, SPP
Illumination location	Front
Volume control	Digital
Power source	Battery
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	20
Recording on	USB
Playback modes	Normal, Repeat, Shuffle
Playback disc formats	CD audio, DVD-Audio, VCD
Audio formats supported	AAC, MP3, WAV, WMA
Video formats supported	MPEG1, MPEG4, XVID

Weight and Dimensions

Depth	300 mm
Width	328 mm
Height	799 mm
Weight	12600 g
