2-1
DVP-NS975V
Note: Follow the disassembly procedure in the numerical order given.
2-1. UPPER CASE
SECTION 2
DISASSEMBLY
2-2. FRONT PANEL ASSEMBLY
5
1
Screw, Tapping
2
Screw, Tapping
6
Tray cover
3 Three screws
(Screw +BV3 (3-CR))
4
Chassis back
1
Claw
2
Two claws
3
Two claws
1
Claw
a
b
c
b
a
c
4
Front panel assembly
