Sony RMT-D172A - Board; Switching Regulator

2-5
DVP-NS975V
2-7. MB-118 BOARD
a
a
d
e
f
d
e
f
qg IM-072 harness
(CN402, 7P)
9 MD-105 harness
(CN201, 6P)
qa FMA-012 flexible cable
(CN301, 25P)
0 FMO-013 flexible cable
(CN101, 24P)
qs FMA-013 flexible cable
(CN201, 17P)
qh FIM-006 flexible cable
(CN106, 13P)
8 FMS-002 flexible cable
(CN202, 5P)
qf PM-117 harness
(CN401, 10P)
qd AM-144 harness
(CN403, 7P)
MB-118 board
2-8. SWITCHING REGULATOR
2 PM-117 harness
(CN201, 10P)
1 Two screws
SUMITITE (B3), +BV
3 Power board
