DVP-NS975V
B
C
A
1
2
765
43
POWER BLOCK (SRV1579WW) PRINTED WIRING BOARD
POWER BOARD A SIDE (SRV1579WW)
For printed wiring board
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
POWER BOARD
(SRV1579WW)
A SIDE
IC101 B-4
IC501 A-7
IC502 C-6
Q401 B-7
Q501 B-6
D101 B-3
D102 B-3
D103 B-3
D104 B-3
D105 C-4
D106 B-4
D107 A-3
D108 B-4
D201 C-5
D202 C-5
D301 A-5
D302 B-6
D401 B-5
D402 A-6
D404 B-7
D501 B-5
D601 C-5
B SIDE
Q301 B-2
Q302 B-2
4-35 4-36
POWER BOARD
POWER BLOCK (SRV1579WW)
• : Uses unleaded solder.
•
E
B
C
A
1
2
765
43
Power board
PL-035 board
(POWER SWITCH)
IF-115 board
(INTERFACE)
AV-086 board
(VIDEO, AUDIO)
MB-118 board
(SYSTEM, SERVO, 8ch DAC,
PS-TROUGH, PROGE, HDMI)
