8-4
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film
resistor.
F: nonflammable
• Not all of the parts for POWER BLOCK
(HS12S2U) are listed.
• Items marked “*” are not stocked since
they are seldom required for routine
service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
E : Latin America model
KR : Korea model
8-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark or dotted line with mark
are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DVP-NS975V
A-1063-898-A MB-118 COMPLETE (US,CND)
A-1075-849-A MB-118 COMPLETE (E)
A-1082-061-A MB-118 COMPLETE (KR)
<CAPACITOR>
C101 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C102 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C105 1-126-205-11 ELECT CHIP 47UF 20.00% 6.3V
C106 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C107 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C108 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C109 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C110 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C111 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C112 1-126-205-11 ELECT CHIP 47UF 20.00% 6.3V
C113 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C114 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C115 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C116 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C117 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C118 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C119 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C120 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C121 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C122 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C123 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C124 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C125 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C126 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C127 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C128 1-162-965-11 CERAMIC CHIP 0.0015UF 10.00% 50V
C129 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C130 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C131 1-125-838-11 CERAMIC CHIP 2.2UF 10% 6.3V
C132 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C133 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C135 1-164-677-11 CERAMIC CHIP 0.033UF 10.00% 16V
C136 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C137 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C138 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
MB-118
C139 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V
C140 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C141 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C142 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C143 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C144 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C145 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C146 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C147 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C148 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C149 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C150 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C151 1-115-416-11 CERAMIC CHIP 0.001UF 5.00% 25V
C152 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C153 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C154 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C155 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C156 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C158 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C159 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C160 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C161 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C162 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C163 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C164 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C167 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C170 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C171 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C172 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C173 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C174 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C175 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C176 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C177 1-126-205-11 ELECT CHIP 47UF 20.00% 6.3V
C178 1-126-208-21 ELECT CHIP 47UF 20.00% 4V
C179 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C180 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C181 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C182 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C184 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
