8-1
SECTION 8
REPAIR PARTS LIST
The components identified by
mark or dotted line with mark
are critical for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some de-
lay should be anticipated when ordering these
items.
• The mechanical parts with no reference number
in the exploded views are not supplied.
• Color Indication of Appearance Parts Example:
KNOB, BALANCE (WHITE) . . . (RED)
RR
Parts Color Cabinet's Color
8-1. EXPLODED VIEWS
• Abbreviation
E : Latin America model
KR : Korea model
DVP-NS975V
8-1-1. MAIN SECTION
ns : not supplied
