8-2
DVP-NS975V
Note :
The components identified
by mark or dotted line
with mark are critical for
safety.
Replace only with part
number specified.
Note :
Les composants identifiés par
une marque sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1 A-1063-898-A MB-118 BOARD COMPL (US,CND)
1 A-1075-849-A MB-118BOARD COMPL (E)
2 A-1063-904-A AV-086 BOARD COMPL (US,CND,E)
2 A-1063-912-A AV-086 BOARD COMPL (KR)
3 3-077-331-11 +BV3 (3-CR)
4 A-1063-900-A IF-115 BOARD COMPL (US,CND)
4 A-1063-906-A IF-115 BOARD COMPL (E)
4 A-1063-910-A IF-115 BOARD COMPL (KR)
5 1-468-883-11 POWER SUPPLY BLOCK
6 X-3954-297-2 PANEL ASSY, FRONT (US,CND,E)
6 X-2021-575-2 PANEL ASSY, FRONT (KR)
7 4-942-568-61 EMBLEM (NO.5), SONY (US,CND,E)
7 4-942-568-51 EMBLEM (NO.5), SONY (KR)
8 X-3954-282-2 COVER TRAY ASSY (US,CND,E)
8 X-2021-576-1 COVER TRAY ASSY (KR)
9 3-077-331-21 +BV3 (3-CR)
10 3-077-331-31 +BV3 (3-CR)
11 1-828-871-11 POWER-SUPPLY CORD (KR)
11 1-828-451-11 POWER-SUPPLY CORD (US,CND)
12 3-070-883-41 SCREW, TAPPING
13 3-090-263-12 CASE, UPPER (US,CND,E)
13 3-090-263-52 CASE, UPPER (KR)
14 3-088-023-01 +BV3 (3-CR)
15 3-073-096-01 LID, BATTERY CASE
16 1-478-843-31 REMOTE COMMANDER (RMT-D172A)
19 3-087-053-01 +BVTP2.6 (3CR)
20 3-831-441-11 CUSHION (F)
21 X-3954-284-1 FOOT (R) ASSY
22 X-3954-283-1 FOOT (F) ASSY
23 2-055-460-01 SPECIAL SCREW (2.6X6, B)
24 1-829-174-11 FLAT FLEXIBLE CABLE (FMO-013)
25 1-829-386-11 FLAT FLEXIBLE CABLE (FMS-002)
26 1-963-012-11 FLEXIBLE FLAT CABLE (FIM-006)
27 1-963-013-11 FLEXIBLE FLAT CABLE (FMA-012)
28 1-963-014-11 FLEXIBLE FLAT CABLE (FMA-013)
29 1-963-017-11 FLEXIBLE FLAT CABLE (FIP-002)
