HCD-SHAKE99/HCDSHAKE100
9
1 three screws
(+BVTP 3 u 10) (BLACK)
2 one screw
(+BVTP 3 u 10) (BLACK)
2 one screw
(+BVTP 3 u 10) (BLACK)
8 one screw
(+BVTP 3 u 10) (BLACK)
9 one screw
(+BVTP 3 u 10)
(BLACK)
qa one screw
(+BVTP 3 u 8)
7 hemilon,
15.0 u 30.0 u 1.75
qf hemilon,
15.0 u 30.0 u 1.75
qk one screw
(+BVTP 3 u 8)
0 two screws
(+BVTP 3 u 10) (BLACK)
qd panel, side-L assy
qs
ql
qh one screw
(+BVTP 3 u 10) (BLACK)
qj two screws
(+BVTP 3 u 10) (BLACK)
w; panel, side-R assy
qg one screw
(+BVTP 3 u 10)
(BLACK)
6 case, top
5 two screws
(+BVTP 3 u 8)
5 three screws
(+BVTP 3 u 8)
5 three screws
(+BVTP
3 u 8)
5 three screws
(+BVTP 3 u 8)
5 four screws
(+BVTP 3 u 8)
5 one screw
(+BVTP 3 u 8)
4 panel, top
3
B
A
B
A
(EXCEPT
SHAKE99: US)
(SHAKE99: US)
(SHAKE99: US)
5 one screw
(+BVTP 3 u 8)
(EXCEPT
SHAKE99: US)
Note: Follow the disassembly procedure in the numerical order given.
2-1. PANEL, TOP, CASE, TOP, PANEL, SIDE-L ASSY, PANEL, SIDE-R ASSY
Ver. 1.2
