Sony SHAKE-99D - Back Panel Section

82
HCD-SHAKE99/HCDSHAKE100
front panel section
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
not supplied
not supplied
not supplied
(VIDEO board)
not supplied
not
supplied
CD MECHANISM
section
MOTHERBOARD board
section
not supplied
not supplied
not supplied
(TUNER board)
52
51
53
51
K
L
M
K
L
N
N
M
not supplied
(HCDSHAKE100)
(SHAKE99: US, AUS/
HCDSHAKE100: EA, MY, SAF)
(HCDSHAKE100)
7-2. BACK PANEL SECTION
0 51 1-855-006-51 DC FAN
52 1-848-365-21 FLEXIBLE FLAT CABLE (9 CORE)
53 1-500-082-11 CLAMP, SLEEVE FERRITE (SHAKE99: US, AUS/
HCDSHAKE100: EA, MY, SAF)
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark
Note: If fl exible fl at cable is replaced, install it after bending
it in the same form as that before replacement.
Ver. 1.2
