87
HCD-SHAKE99/HCDSHAKE100
SECTION 8
ELECTRICAL PARTS LIST
A-1977-063-A 10CH DAMP BOARD, COMPLETE
**************************
< CAPACITOR >
C1000 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1003 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1004 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1005 1-112-800-11 ELECT CHIP 100uF 20% 35V
C1006 1-112-800-11 ELECT CHIP 100uF 20% 35V
C1007 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1008 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1010 1-118-291-11 CERAMIC CHIP 100PF 5% 50V
C1011 1-112-800-11 ELECT CHIP 100uF 20% 35V
C1012 1-112-800-11 ELECT CHIP 100uF 20% 35V
C1013 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1014 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1016 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1019 1-128-992-21 ELECT CHIP 47uF 20% 25V
C1020 1-128-992-21 ELECT CHIP 47uF 20% 25V
C1021 1-126-204-11 ELECT CHIP 47uF 20% 16V
C1022 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1023 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1024 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1025 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1026 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1027 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C1028 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C1030 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C1032 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1033 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1034 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1035 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
C1036 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
C1038 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1039 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1042 1-112-723-21 CERAMIC CHIP 0.0047uF 10% 250V
C1044 1-118-978-11 CERAMIC CHIP 0.47uF 10% 250V
C1046 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1047 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1048 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C1050 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1052 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1053 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1054 1-112-723-21 CERAMIC CHIP 0.0047uF 10% 250V
C1055 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1057 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1059 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
* C1063 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1066 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1067 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
* C1069 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1070 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1071 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1072 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1076 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C1078 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1079 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1080 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1081 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1082 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1083 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C1084 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1086 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1087 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1089 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1090 1-124-779-00 ELECT CHIP 10uF 20% 16V
C1092 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
* C1093 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1094 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1095 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1096 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1099 1-118-978-11 CERAMIC CHIP 0.47uF 10% 250V
C1101 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
* C1102 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1103 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1105 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
C1106 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
C1107 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1108 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1109 1-118-626-11 ELECT 4700uF 20% 71V
C1110 1-118-626-11 ELECT 4700uF 20% 71V
C1111 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1112 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1113 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1114 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1117 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1121 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C1122 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C1123 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1124 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
10CH DAMP
• Abbreviation
AR : Argentina model
AUS : Australian model
E2 : 120V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
MY : Malaysia model
SAF : South African model
Ver. 1.1
When indicating parts by reference num-
ber, please include the board name.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
To Next Page
