Ref. No. Part No. Description Remark
HCD-SHAKE99/HCDSHAKE100
110
Note: If fl exible fl at cable, wires (fl at type), ffc 8P and cable,
fl exible fl at is replaced, install it after bending it in the same
form as that before replacement.
R2055 1-216-809-11 METAL CHIP 100 5% 1/10W
R2056 1-216-809-11 METAL CHIP 100 5% 1/10W
R2057 1-216-809-11 METAL CHIP 100 5% 1/10W
R2059 1-216-809-11 METAL CHIP 100 5% 1/10W
R2060 1-216-819-11 METAL CHIP 680 5% 1/10W
R2062 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2063 1-216-803-11 METAL CHIP 33 5% 1/10W
R2064 1-216-806-11 METAL CHIP 56 5% 1/10W
R2068 1-216-801-11 METAL CHIP 22 5% 1/10W
< SWITCH >
S2000 1-786-417-11 ENCODER, ROTARY (VOLUME / DJ CONTROL)
*************************************************************
MISCELLANEOUS
**************
0 51 1-855-006-51 DC FAN
52 1-848-365-21 FLEXIBLE FLAT CABLE (9 CORE)
53 1-500-082-11 CLAMP, SLEEVE FERRITE (SHAKE99: US, AUS/
HCDSHAKE100: EA, MY, SAF)
102 1-848-364-21 FLEXIBLE FLAT CABLE (23 CORE)
103 1-848-363-21 FLEXIBLE FLAT CABLE (10 CORE)
104 1-848-362-21 FLEXIBLE FLAT CABLE (10 CORE)
105 1-828-316-21 WIRE (FLAT TYPE) (11 CORE)
* 106 3-703-150-11 CLAMP
107 1-828-298-21 WIRE (FLAT TYPE) (7 CORE)
110 8-989-470-00 RC-S801/A (WW)
111 1-848-367-61 FFC 8P (8 CORE)
112 1-492-699-11 BLUETOOTH MODULE
113 1-848-366-61 FLEXIBLE FLAT CABLE (10 CORE)
152 1-828-396-21 WIRE (FLAT TYPE) (27 CORE)
0 153 1-855-006-51 DC FAN
* 202 3-703-150-11 CLAMP
203 1-457-369-12 CORE, FERRITE (SHAKE99: US, AUS/
HCDSHAKE100: EA, MY, SAF)
0 204 1-848-147-11 POWER-SUPPLY CORD (EA, MY)
0 204 1-848-148-12 POWER-SUPPLY CORD (E2, MX)
0 204 1-848-149-11 POWER-SUPPLY CORD (SAF)
0 204 1-848-677-11 POWER-SUPPLY CORD (AUS)
0 204 1-848-222-11 POWER-SUPPLY CORD (US)
0 204 1-848-273-11 POWER-SUPPLY CORD (AR)
0 204 1-848-274-12 POWER-SUPPLY CORD (E51)
0 205 1-474-550-11 SWITCHING REGULATOR
251 A-1896-391-B LOADING COMPLETE ASSY (T)
(including MS-476 board)
0 254 A-2046-956-A SERVICE, OPTICAL DEVICE(7G)
255 1-828-293-21 WIRE (FLAT TYPE) (5 CORE)
256 1-836-504-11 CABLE, FLEXIBLE FLAT (24 CORE)
VOLUME
Ver. 1.2
