Sony SHAKE-99D - Page 120

SPK RGB LED BOARD
*****************
< CONNECTOR >
*
CN3600 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER L/R)
< DIODE >
D3600 6-503-944-51 DI SMLVN6RGB1U17QYB
< RESISTOR >
R3601 1-216-801-11 METAL CHIP 22 5% 1/10W
************************************************************
SPK SPLITTER BOARD
******************
< CONNECTOR >
CN3500 1-779-992-11 PIN, CONNECTOR (PWB) 8P (LED SPEAKER L/R)
CN3501 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN3502 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
************************************************************
STROBE+RGB_1 BOARD
********************
< CONNECTOR >
CN3700 1-774-731-21 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D3701 6-503-944-51 DI SMLVN6RGB1U17QYB
D3702 6-503-944-51 DI SMLVN6RGB1U17QYB
D3703 6-504-045-01 DI TL2FK-DW1, L
< RESISTOR >
R3704 1-216-805-11 METAL CHIP 47 5% 1/10W
R3705 1-216-805-11 METAL CHIP 47 5% 1/10W
R3706 1-216-807-11 METAL CHIP 68 5% 1/10W
R3707 1-216-807-11 METAL CHIP 68 5% 1/10W
R3708 1-216-807-11 METAL CHIP 68 5% 1/10W
R3709 1-216-805-11 METAL CHIP 47 5% 1/10W
R3710 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R3711 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R3712 1-216-793-11 METAL CHIP 4.7 5% 1/10W
************************************************************
STROBE+RGB_2 BOARD
*******************
< CONNECTOR >
CN3800 1-770-161-21 PIN, CONNECTOR (PC BOARD) 6P
< DIODE >
D3800 6-504-045-01 DI TL2FK-DW1, L
D3801 6-503-944-51 DI SMLVN6RGB1U17QYB
D3802 6-503-944-51 DI SMLVN6RGB1U17QYB
< RESISTOR >
R3804 1-216-805-11 METAL CHIP 47 5% 1/10W
R3805 1-216-805-11 METAL CHIP 47 5% 1/10W
R3806 1-216-807-11 METAL CHIP 68 5% 1/10W
R3807 1-216-807-11 METAL CHIP 68 5% 1/10W
R3808 1-216-807-11 METAL CHIP 68 5% 1/10W
R3809 1-216-805-11 METAL CHIP 47 5% 1/10W
R3810 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R3811 1-216-793-11 METAL CHIP 4.7 5% 1/10W
6
SS-SHAKE99/SHAKE100
SECTION 3
ELECTRICAL PARTS LIST
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “
*
” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
The components identified by mark
0
or dotted line with mark
0
are critical for
safety.
Replace only with part number specifi ed.
SPK RGB LED SPK SPLITTER
STROBE+RGB
_
1 STROBE+RGB
_
2
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• Abbreviation
AR : Argentina model
AUS : Australian model
E2 : 120V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
MY : Malaysia model
SAF : South African model
Ver. 1.1
