SERVICE MANUAL
Sony Corporation
Published by Sony EMCS (Malaysia) PG Tec
HCD-SHAKE99/
HCDSHAKE100
HOME AUDIO SYSTEM
9-890-632-03
2014G80-1
©
2014.07
US Model
E Model
Argentina Model
Australian Model
Mexican Model
HCD-SHAKE99
Malaysia Model
Saudi Arabia Model
South African Model
HCDSHAKE100
Ver. 1.2 2014.07
• HCD-SHAKE99 is the tuner, USB, CD Player, Bluetooth, NFC and amplifi er section in SHAKE-99.
• HCDSHAKE100 is the tuner, USB, DVD Player, Bluetooth, NFC and amplifi er section in SHAKE-100D.
SPECIFICATIONS
CD/DVD Section
Model Name Using Similar Mechanism NEW
CD Mechanism Type CDM90-DVBU202//M
Optical Pick-up Name CMS-S76RFS7G
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(US model only)
With 10 ohm loads, both channels driven, from
100 – 3,000 Hz; rated 500 watts per channel
minimum RMS power, with no more than 0.7%
total harmonic distortion from 250 milliwatts
to rated output.
Amplifi er section
The following are measured at
US model:
AC 120 V, 60 Hz
MX model:
AC 120 V – 240 V, 60 Hz
AR model (SHAKE-99):
AC 220 V – 240 V, 50/60 Hz
E51 model:
AC 220 V – 240 V, 50 Hz
AUS model (SHAKE-99):
AC 230 V – 240 V, 50/60Hz
Other models:
AC 120 V – 240 V, 50/60 Hz
WF (Woofers)
Power Output (rated):
700 W + 700 W (at 10 ohms, 1 kHz,
1% THD)
RMS output power (reference):
900 W + 900 W (per channel at
10 ohms, 1 kHz)
MID (Mid speakers)/TW (Tweeters)
RMS output power (reference):
300 W + 300 W (per channel at
8 ohms, 2 kHz)
SW (Subwoofers)
RMS output power (reference):
1,200 W + 1,200 W (per channel at
8 ohms, 100 Hz)
Inputs
AUDIO IN 1/PARTY CHAIN IN L/R
Voltage 2 V, impedance 47 kilohms
AUDIO IN 2 L/R
Voltage 2 V, impedance 47 kilohms
MIC
Sensitivity 1 mV, impedance 10 kilohms
(USB) A, (USB) B port
Type A
Outputs
AUDIO OUT/PARTY CHAIN OUT L/R
Voltage 2 V, impedance 1 kilohm
VIDEO OUT (SHAKE-100D)
Max. output level 1 Vp-p, unbalanced,
Sync. negative load impedance
75 ohms
USB section
Supported bit rate
WMA:
48 kbps – 192 kbps, VBR, CBR
AAC:
48 kbps – 320 kbps, VBR, CBR
Sampling frequencies
WMA: 44.1 kHz
AAC: 44.1 kHz
Supported USB device
Mass Storage Class
Maximum current
500 mA
Disc/USB section
Supported bit rate
MPEG1 Layer-3:
32 kbps – 320 kbps, VBR
MPEG2 Layer-3:
8 kbps – 160 kbps, VBR
MPEG1 Layer-2:
32 kbps – 384 kbps, VBR
Sampling frequencies
MPEG1 Layer-3:
32 kHz/44.1 kHz/48 kHz
MPEG2 Layer-3:
16 kHz/22.05 kHz/24 kHz
MPEG1 Layer-2:
32 kHz/44.1 kHz/48 kHz
Disc player section
System
Compact disc and digital audio and
video system (SHAKE-100D)
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6 µW
* This output is the value
measurement at a distance of
200 mm from the objective lens
surface on the Optical Pick-up
Block with 7 mm aperture.
Frequency response
20 Hz – 20 kHz
Video color system format (SHAKE-100D)
NTSC and PAL
Signal-to-noise ratio
More than 90 dB
Dynamic range
More than 88 dB
Tuner section
FM stereo, FM/AM superheterodyne tuner
Antenna:
FM lead antenna
AM loop antenna
FM tuner section
Tuning range
US
model:
87.5 MHz – 108.0 MHz
(100 kHz step)
Other models:
87.5 MHz – 108.0 MHz
(50 kHz step)
AM tuner section
Tuning range
AUS, E2, E51, US, CND, MX, AR
models:
531 kHz – 1,710 kHz (9 kHz step)
530 kHz – 1,710 kHz (10 kHz step)
Other models:
531 kHz – 1,602 kHz (9 kHz step)
530 kHz – 1,610 kHz (10 kHz step)
Bluetooth section
Communication system
Bluetooth Standard version 3.1
Output
Bluetooth Standard Power Class 2
Maximum communication range
Line of sight approx. 10m
1)
Frequency band (SHAKE-100D)
2.4 GHz band (2.4000 GHz –
2.4835 GHz)
Modulation method (SHAKE-100D)
FHSS (Freq Hopping Spread
Spectrum)
Compatible Bluetooth profiles
2)
(SHAKE-100D)
A2DP (Advanced Audio Distribu-
tion Profile)
AVRCP 1.3 (Audio Video Remote
Control Profile)
Supported codecs (SHAKE-100D)
SBC (Sub Band Codec)
AAC (Advanced Audio Coding)
1)
The actual range will vary depending on
factors such as obstacles between devices,
magnetic fields around a microwave oven,
static electricity, reception sensitivity,
antenna’s performance, operating system,
software application, etc.
2)
Bluetooth standard profiles indicate the
purpose of Bluetooth communication
between devices.
Speakers
SS-SHAKE100 for SHAKE-100D
SS-SHAKE99 for SHAKE-99
Speaker system
4-way, Sound Pressure Horn and Bass
Refl ex
Speaker unit
Woofers: 250 mm (9
⁄
in), cone type
Tweeters: 25 mm (1 in), horn type
Mid speakers: 100 mm (4 in), cone
type
Subwoofers: 460 mm (18 in), cone
type
Rated impedance
Mid speakers/tweeters: 8 ohms
Woofers: 10 ohms
Subwoofers: 8 ohms
Dimensions (w/h/d) (Approx.)
610 mm × 945 mm × 500 mm
(
24
⁄
in
× 37
⁄
in × 19
⁄
in)
Mass (Approx.)
51.0 kg (112 lb 7 oz)
Quantity: 2 pieces
– Continued on next page –
Photo: HCD-SHAKE99
