Sony SHAKE-99D - Page 70

HCD-SHAKE99/HCDSHAKE100
68
IC452 BA2903FV-E2 (MOTHERBOARD BOARD (5/9))
VCC
GND
+
–
+
–
8
7
6
5
B OUTPUT B- INPUT B+ INPUT
1
2
3
4
A OUTPUT
A- INPUT
A+ INPUT
V-
V+
Ver. 1.1
IC451 GL850G-OGY33 (MOTHERBOARD BOARD (5/9))
24
DP0
23
DM0
22
AVDD_22
21
PWREN1/SDA
20
OVCUR1/SMC
19
PWREN2
14
RESET
13
DP4
18
OVCUR2/SMD
17
PGANG
16
DVDD
15
TEST/SCL
1
DM1
2
DP1
3
DM2
4
DP2
5
RREF
6
AVDD_6
7
X1
8
X2
9
DM3
10
DP3
11
AVDD_11
12
DM4
USPORT
Transceiver
DSPORT
Transceiver
DSPORT
Transceiver
DSPORT
Transceiver
DSPORT
Transceiver
USPORT
Logic
Control/Status
Register
PLL
x40, x10
RAM ROM
CPU
FRTIMER
UTMI
REPEATER
DSPORT1 Logic DSPORT2 Logic DSPORT3 Logic DSPORT4 Logic
TT (Transaction Translator)
REPEATER / TT Routing Logic
SIE
