8-11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-315
C881 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
(E580EE)
C882 1-126-967-11 ELECT 47uF 20% 16V
(E580EE)
C884 1-126-964-11 ELECT 10uF 20% 50V
(E580EE)
C885 1-126-964-11 ELECT 10uF 20% 50V
(E580EE)
< CONNECTOR >
CN101 1-779-724-11 CONNECTOR, BOARD TO BOARD 5P
CN102 1-779-723-11 CONNECTOR, BOARD TO BOARD 9P
CN104 1-766-716-11 CONNECTOR, BOARD TO BOARD 3P
* CN161 1-568-954-11 PIN, CONNECTOR 5P (E780)
CN161 1-506-469-11 PIN, CONNECTOR 4P (E580)
CN162 1-506-468-11 PIN, CONNECTOR 3P
* CN163 1-568-954-11 PIN, CONNECTOR 5P
CN164 1-784-495-11 CONNECTOR, FFC/FPC 16P
CN305 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
* CN306 1-766-718-21 CONNECTOR, BOARD TO BOARD 17P
CN500 1-784-415-11 CONNECTOR, SQUARE TYPE 21P (LINE 1)
CN570 1-784-415-11 CONNECTOR, SQUARE TYPE 21P (LINE 3)
(EXCEPT E580EE/E630AE/E780EE)
CN600 1-569-341-11 CONNECTOR, BOARD TO BOARD 19P
< DIODE >
D101 8-719-200-82 DIODE 11ES2
D102 8-719-048-26 DIODE GL528V1
D104 8-719-109-97 DIODE RD6.8ES-B2
D161 8-719-200-82 DIODE 11ES2
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
D163 8-719-200-82 DIODE 11ES2
D164 8-719-200-82 DIODE 11ES2
D165 8-719-109-97 DIODE RD6.8ES-B2
D166 8-719-109-97 DIODE RD6.8ES-B2
D167 8-719-109-97 DIODE RD6.8ES-B2
D168 8-719-109-97 DIODE RD6.8ES-B2
D169 8-719-109-97 DIODE RD6.8ES-B2
D500 8-719-109-97 DIODE RD6.8ES-B2
D501 8-719-109-97 DIODE RD6.8ES-B2
D502 8-719-109-97 DIODE RD6.8ES-B2 (EXCEPT E580)
D503 8-719-109-97 DIODE RD6.8ES-B2 (EXCEPT E580)
D504 8-719-109-97 DIODE RD6.8ES-B2
D505 8-719-109-97 DIODE RD6.8ES-B2
D506 8-719-109-97 DIODE RD6.8ES-B2 (EXCEPT E580EG)
D507 8-719-109-97 DIODE RD6.8ES-B2 (EXCEPT E580EG)
D508 8-719-109-97 DIODE RD6.8ES-B2
D509 8-719-109-97 DIODE RD6.8ES-B2 (EXCEPT E580EG/E630)
D511 8-719-109-97 DIODE RD6.8ES-B2
D512 8-719-921-86 DIODE MTZJ-13
D513 8-719-109-97 DIODE RD6.8ES-B2
D514 8-719-109-97 DIODE RD6.8ES-B2
D515 8-719-109-97 DIODE RD6.8ES-B2
D516 8-719-109-97 DIODE RD6.8ES-B2
D540 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT E580EE/E630AE/E780EE)
D541 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT E580EE/E630AE/E780EE)
D542 8-719-109-97 DIODE RD6.8ES-B2
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
D543 8-719-109-97 DIODE RD6.8ES-B2
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
D544 8-719-109-97 DIODE RD6.8ES-B2
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
D570 8-719-109-97 DIODE RD6.8ES-B2
D571 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT E580EE/E630AE/E780EE)
D572 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT E580EE/E630AE/E780EE)
D573 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT E580/E630AE/E780EE)
D574 8-719-109-97 DIODE RD6.8ES-B2
(EXCEPT E580/E630AE/E780EE)
D575 8-719-109-97 DIODE RD6.8ES-B2
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
D576 8-719-109-97 DIODE RD6.8ES-B2
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
D577 8-719-109-97 DIODE RD6.8ES-B2
(E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
D578 8-719-109-97 DIODE RD6.8ES-B2
(E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
D580 8-719-911-19 DIODE 1SS119 (E580)
D581 8-719-911-19 DIODE 1SS119
D582 8-719-109-97 DIODE RD6.8ES-B2
D583 8-719-109-97 DIODE RD6.8ES-B2
D661 8-719-911-19 DIODE 1SS119
D662 8-719-911-19 DIODE 1SS119
D700 8-719-911-19 DIODE 1SS119 (EXCEPT E580)
D702 8-719-982-26 DIODE MTZJ-33B
D751 8-719-109-85 DIODE RD5.1ES-B2
D752 8-719-911-19 DIODE 1SS119
< FILTER >
FL500 1-236-163-11 ENCAPSULATED COMPONENT
FL501 1-236-163-11 ENCAPSULATED COMPONENT (EXCEPT E580)
FL502 1-236-163-11 ENCAPSULATED COMPONENT
FL503 1-236-163-11 ENCAPSULATED COMPONENT
(EXCEPT E580EG)
FL504 1-236-163-11 ENCAPSULATED COMPONENT
(EXCEPT E580EG/E630)
FL505 1-236-163-11 ENCAPSULATED COMPONENT
(EXCEPT E580EG/E630)
FL570 1-236-163-11 ENCAPSULATED COMPONENT
(EXCEPT E580EE/E630AE/E780EE)
FL571 1-236-163-11 ENCAPSULATED COMPONENT
(EXCEPT E580/E630AE/E780EE)
FL572 1-236-163-11 ENCAPSULATED COMPONENT
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
FL573 1-236-163-11 ENCAPSULATED COMPONENT
(E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
FL660 1-233-527-11 FILTER, TRAP
