8-12
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-315
< IC >
IC130 8-759-481-46 IC LB1943
IC161 8-759-482-27 IC M37777MAA104GP
(EXCEPT E580EE/E630/E780EE)
IC161 8-759-495-33 IC M37777MAA105GP (E630)
IC161 8-759-482-29 IC M37777M7A238GP-C (E580EE/E780EE)
IC162 8-759-248-87 IC MM1256XF-BE
IC163 8-759-454-78 IC 24LC08BT/SN
IC201 8-759-479-25 IC LA71514M-MPB
IC202 8-759-439-50 IC LC89977M-TE-L
IC360 8-759-486-63 IC TDA9615H/N1,518 (EXCEPT E580)
! IC530 8-759-438-18 IC PQ12RD08
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
IC540 8-759-438-16 IC STV6400D
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
IC580 8-759-300-71 IC HD14053BFP (E580EG)
IC660 8-759-480-27 IC LC74790M-9693-TLM
(E630/E727/E730/E735)
IC660 8-759-480-26 IC LC74790M-9702-TLM (E580/E780)
IC850 8-759-484-61 IC SDA5650X-GEG
(EXCEPT E580EE/E630/E780EE)
IC870 8-759-988-36 IC BA14741F (E580EE)
< JACK >
J500 1-784-414-11 JACK, PIN 2P (LINE 2 OUT)
(E727/E730/E735/E780: EG, EN)
J500 1-784-412-11 JACK, PIN 3P (LINE 2 OUT) (E780EE)
J500 1-784-413-11 JACK, PIN 3P (LINE 2 OUT) (E580EE)
< JUMPER RESISTOR >
JR001 1-216-296-91 SHORT 0
JR002 1-216-296-91 SHORT 0
JR003 1-216-296-91 SHORT 0
JR004 1-216-296-91 SHORT 0
JR005 1-216-296-91 SHORT 0
JR006 1-216-296-91 SHORT 0
JR007 1-216-295-91 SHORT 0
JR008 1-216-296-91 SHORT 0
JR009 1-216-296-91 SHORT 0
JR010 1-216-295-91 SHORT 0
JR011 1-216-296-91 SHORT 0 (EXCEPT E580)
JR012 1-216-296-91 SHORT 0
JR013 1-216-295-91 SHORT 0
JR014 1-216-296-91 SHORT 0
JR015 1-216-295-91 SHORT 0
JR016 1-216-295-91 SHORT 0
JR017 1-216-296-91 SHORT 0 (E580)
JR018 1-216-296-91 SHORT 0 (E580)
JR019 1-216-296-91 SHORT 0
JR020 1-216-296-91 SHORT 0
JR021 1-216-295-91 SHORT 0
JR022 1-216-296-91 SHORT 0
JR023 1-216-296-91 SHORT 0
JR024 1-216-296-91 SHORT 0
JR025 1-216-296-91 SHORT 0
JR026 1-216-295-91 SHORT 0
JR027 1-216-295-91 SHORT 0
JR028 1-216-296-91 SHORT 0 (E580)
JR029 1-216-296-91 SHORT 0 (E580EE)
JR030 1-216-296-91 SHORT 0
JR031 1-216-295-91 SHORT 0 (E580EE)
JR032 1-216-295-91 SHORT 0 (E580)
JR033 1-216-296-91 SHORT 0
JR034 1-216-295-91 SHORT 0
JR035 1-216-295-91 SHORT 0
JR036 1-216-295-91 SHORT 0
JR037 1-216-295-91 SHORT 0
JR038 1-216-296-91 SHORT 0
JR039 1-216-295-91 SHORT 0
JR040 1-216-296-91 SHORT 0
(EXCEPT E580EE/E630/E780EE)
JR041 1-216-295-91 SHORT 0
JR042 1-216-296-91 SHORT 0
JR043 1-216-296-91 SHORT 0
JR044 1-216-296-91 SHORT 0
JR045 1-216-295-91 SHORT 0
JR046 1-216-296-91 SHORT 0
JR047 1-216-295-91 SHORT 0
JR048 1-216-296-91 SHORT 0
JR049 1-216-296-91 SHORT 0
JR050 1-216-296-91 SHORT 0
JR051 1-216-295-91 SHORT 0
JS201 1-216-295-91 SHORT 0
JS500 1-216-295-91 SHORT 0 (E580)
JS501 1-216-295-91 SHORT 0 (E580EG)
JS502 1-216-295-91 SHORT 0 (EXCEPT E580EG)
JS503 1-216-295-91 SHORT 0 (EXCEPT E580EG)
JS504 1-216-295-91 SHORT 0 (EXCEPT E580EG)
JS541 1-216-295-91 SHORT 0
(E580EE/E630AE/E730: EX, NC, UX, VP/
E735NC/E780EE)
JS542 1-216-295-91 SHORT 0
(E580EE/E630AE/E730: EX, NC, UX, VP/
E735NC/E780EE)
JS570 1-216-295-91 SHORT 0 (E580EG)
JS571 1-216-295-91 SHORT 0 (E580EG)
JS572 1-216-295-91 SHORT 0 (EXCEPT E580EG)
JS573 1-216-295-91 SHORT 0 (EXCEPT E580EG)
JS575 1-216-295-91 SHORT 0 (EXCEPT E580)
JS576 1-216-295-91 SHORT 0 (E580)
JS700 1-216-296-91 SHORT 0 (E780EE)
JS701 1-216-295-91 SHORT 0 (E780EE)
< COIL >
L161 1-414-936-21 INDUCTOR 22uH
L162 1-414-936-21 INDUCTOR 22uH
L163 1-414-936-21 INDUCTOR 22uH
L164 1-414-936-21 INDUCTOR 22uH
L201 1-414-946-21 INDUCTOR 39uH
L202 1-414-940-21 INDUCTOR 100uH
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
