Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-315
L203 1-469-014-21 INDUCTOR 120uH
L204 1-414-934-21 INDUCTOR 10uH
L205 1-414-940-21 INDUCTOR 100uH
L206 1-414-934-21 INDUCTOR 10uH
L207 1-414-934-21 INDUCTOR 10uH
L301 1-414-940-21 INDUCTOR 100uH
L361 1-414-940-21 INDUCTOR 100uH (EXCEPT E580)
L510 1-414-940-21 INDUCTOR 100uH
L530 1-414-940-21 INDUCTOR 100uH
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
L540 1-414-934-21 INDUCTOR 10uH
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
L580 1-414-940-21 INDUCTOR 100uH (E580)
L661 1-414-940-21 INDUCTOR 100uH
L662 1-414-936-21 INDUCTOR 22uH
(E580/E730B/E735B/E780)
L663 1-414-940-21 INDUCTOR 100uH
L700 1-414-934-21 INDUCTOR 10uH (E780EE)
L701 1-414-930-21 INDUCTOR 2.2uH
L750 1-414-930-21 INDUCTOR 2.2uH
L751 1-414-930-21 INDUCTOR 2.2uH (E580/E780EE)
< PHOTO INTERRUPTER >
PH100 8-749-013-23 PHOTO INTERRUPTER GP3S120
PH101 8-749-013-23 PHOTO INTERRUPTER GP3S120
< IC LINK >
! PS100 1-533-586-31 LINK, IC 491.315 (0.315A)
! PS131 1-533-586-31 LINK, IC 491.315 (0.315A)
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
< TRANSISTOR >
Q100 8-729-043-84 TRANSISTOR PT380F3
Q101 8-729-043-84 TRANSISTOR PT380F3
Q102 8-729-281-53 TRANSISTOR 2SC1815-GR
Q161 8-729-804-41 TRANSISTOR 2SB1122-S
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
Q162 8-729-421-19 TRANSISTOR UN2213
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
Q201 8-729-422-27 TRANSISTOR 2SD601A-Q
Q202 8-729-422-27 TRANSISTOR 2SD601A-Q
Q208 8-729-422-27 TRANSISTOR 2SD601A-Q
Q209 8-729-216-22 TRANSISTOR 2SA1162
Q210 8-729-422-27 TRANSISTOR 2SD601A-Q
Q211 8-729-422-27 TRANSISTOR 2SD601A-Q
Q301 8-729-281-53 TRANSISTOR 2SC1815-GR
Q501 8-729-424-08 TRANSISTOR UN2111
Q502 8-729-421-19 TRANSISTOR UN2213
Q503 8-729-422-27 TRANSISTOR 2SD601A-Q
Q504 8-729-422-27 TRANSISTOR 2SD601A-Q (EXCEPT E580EG)
Q510 8-729-216-22 TRANSISTOR 2SA1162
Q520 8-729-216-22 TRANSISTOR 2SA1162 (E580EE/E780EE)
Q540 8-729-216-22 TRANSISTOR 2SA1162
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
Q580 8-729-422-27 TRANSISTOR 2SD601A-Q (E580)
Q581 8-729-421-19 TRANSISTOR UN2213 (E580EG)
Q582 8-729-421-19 TRANSISTOR UN2213 (E580EG)
Q583 8-729-421-19 TRANSISTOR UN2213 (E580EG)
Q585 8-729-216-22 TRANSISTOR 2SA1162 (EXCEPT E580)
Q660 8-729-216-22 TRANSISTOR 2SA1162
Q661 8-729-216-22 TRANSISTOR 2SA1162
Q662 8-729-216-22 TRANSISTOR 2SA1162
Q700 8-729-027-56 TRANSISTOR DTC143TKA-T146
(EXCEPT E580)
Q701 8-729-216-22 TRANSISTOR 2SA1162 (EXCEPT E580)
Q702 8-729-216-22 TRANSISTOR 2SA1162 (E780EE)
Q730 8-729-027-56 TRANSISTOR DTC143TKA-T146
(EXCEPT E580)
Q731 8-729-027-56 TRANSISTOR DTC143TKA-T146
(EXCEPT E580)
Q750 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q751 8-729-421-19 TRANSISTOR UN2213
Q752 8-729-216-22 TRANSISTOR 2SA1162
Q850 8-729-216-22 TRANSISTOR 2SA1162
(EXCEPT E580EE/E630/E780EE)
Q873 8-729-422-27 TRANSISTOR 2SD601A-Q (E580EE)
Q874 8-729-421-19 TRANSISTOR UN2213 (E580EE)
< RESISTOR >
R100 1-216-089-91 RES, CHIP 47K 5% 1/10W
R101 1-249-413-11 CARBON 470 5% 1/4W F
R102 1-249-429-11 CARBON 10K 5% 1/4W
R103 1-216-089-91 RES, CHIP 47K 5% 1/10W
R104 1-247-863-91 CARBON 22K 5% 1/4W
R105 1-216-081-00 METAL CHIP 22K 5% 1/10W
R106 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R107 1-216-049-91 RES, CHIP 1K 5% 1/10W
R108 1-249-400-11 CARBON 39 5% 1/4W F
R109 1-249-400-11 CARBON 39 5% 1/4W F
R110 1-249-429-11 CARBON 10K 5% 1/4W
R111 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R112 1-216-089-91 RES, CHIP 47K 5% 1/10W
R113 1-216-089-91 RES, CHIP 47K 5% 1/10W
R114 1-216-089-91 RES, CHIP 47K 5% 1/10W
R115 1-216-089-91 RES, CHIP 47K 5% 1/10W
R118 1-216-049-91 RES, CHIP 1K 5% 1/10W
R119 1-216-295-91 SHORT 0
R122 1-216-041-00 METAL CHIP 470 5% 1/10W
R130 1-216-085-00 METAL CHIP 33K 5% 1/10W
R131 1-216-085-00 METAL CHIP 33K 5% 1/10W
R134 1-216-089-91 RES, CHIP 47K 5% 1/10W
R135 1-216-073-00 METAL CHIP 10K 5% 1/10W
R136 1-216-077-00 METAL CHIP 15K 5% 1/10W
R160 1-216-089-91 RES, CHIP 47K 5% 1/10W
R161 1-216-049-91 RES, CHIP 1K 5% 1/10W
(E580EG/E630NP/E727/E730: B, NP, VC/
E735: B, VC/E780: EG, EN)
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
To Next Page
