8-17
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-315 RP-230
S160 1-571-588-31 SWITCH, SLIDE (4.43 ONPAL)
< TUNER >
TU700 1-693-359-12 TUNER, MOD/IF SOLID TYPE (E580EE/E780EE)
TU700 1-693-360-12 TUNER, MOD/IF SOLID TYPE (E580EG)
TU701 8-598-403-00 FSS TUNER BTF-WU601 (E730UX)
TU701 8-598-402-00 FSS TUNER BTF-WC411
(E630NP/E730:NC,NP/E735NC)
TU702 1-693-362-21 TUNER, (IF) SOLID TYPE (E730B/E735B)
TU702 1-693-365-12 TUNER, (IF) SOLID TYPE (E730EX)
TU702 1-693-361-13 TUNER, (IF) SOLID TYPE (E780EG)
TU702 1-693-363-13 TUNER, (IF) SOLID TYPE (E780EN)
TU702 1-693-368-12 TUNER, (IF) SOLID TYPE
(E630AE/E727/E730: VC, VP/E735VC)
< VIBRATOR >
X161 1-760-494-11 VIBRATOR, CRYSTAL (16MHz)
X162 1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz)
X201 1-579-608-11 VIBRATOR, CRYSTAL (4.43MHz)
X660 1-577-289-11 VIBRATOR, CRYSTAL (17.734475MHz)
* A-6791-500-A RP-230 BOARD, COMPLETE (EXCEPT E580)
* A-6791-558-A RP-230 BOARD, COMPLETE (E580)
***********************
(Ref.No. 1,000 Series)
< CAPACITOR >
C260 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C261 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C264 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C265 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C266 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C267 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C268 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C269 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C270 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C271 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C272 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C273 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C274 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C275 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C276 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C277 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C278 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C279 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C280 1-124-584-00 ELECT 100uF 20% 10V
C282 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C283 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C284 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C285 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C286 1-128-057-11 ELECT 330uF 20% 6.3V
C287 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C288 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C289 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C298 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C321 1-126-967-11 ELECT 47uF 20% 16V
C322 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C323 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C324 1-137-397-11 FILM 0.047uF 5% 100V
(EXCEPT E580)
C324 1-137-462-11 FILM 0.018uF 5% 100V
(E580)
C331 1-126-933-11 ELECT 100uF 20% 16V
(E580)
C332 1-164-232-11 CERAMIC CHIP 0.01uF 50V
(E580)
C334 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
(E580)
C335 1-137-397-11 FILM 0.047uF 5% 100V
(E580)
C340 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT E580)
C341 1-124-584-00 ELECT 100uF 20% 10V
(EXCEPT E580)
C342 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT E580)
C346 1-164-232-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT E580)
C350 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT E580)
C352 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT E580)
C353 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EXCEPT E580)
C357 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT E580)
C358 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EXCEPT E580)
C359 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT E580)
< CONNECTOR >
CN260 1-784-492-11 CONNECTOR, FFC/FPC 13P (EXCEPT E580)
CN260 1-784-487-11 CONNECTOR, FFC/FPC 8P (E580)
* CN261 1-564-030-00 PIN, CONNECTOR 5P
CN271 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN272 1-766-720-11 CONNECTOR, BOARD TO BOARD 17P
CN301 1-506-481-11 PIN, CONNECTOR 2P
* CN302 1-568-942-11 PIN, CONNECTOR 4P
* CN341 1-564-027-00 PIN, CONNECTOR 2P (EXCEPT E580)
< IC >
IC260 8-759-352-17 IC HA118195NT
IC301 8-759-499-30 IC BA7755AF-E2
IC340 8-759-486-92 IC LA7256 (EXCEPT E580)
< JUMPER RESISTOR >
JR260 1-216-295-91 SHORT 0
JS331 1-216-295-91 SHORT 0 (EXCEPT E580)
< COIL >
L262 1-414-940-21 INDUCTOR 100uH
L263 1-414-940-21 INDUCTOR 100uH
L321 1-414-940-21 INDUCTOR 100uH
L322 1-414-940-21 INDUCTOR 100uH
L331 1-410-687-11 INDUCTOR 1.2mH
L341 1-414-940-21 INDUCTOR 100uH (EXCEPT E580)
