Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
RP-230 SE-68
< IC LINK >
! PS331 1-533-586-31 LINK, IC 491.315 (0.315A) (E580)
< TRANSISTOR >
Q260 8-729-422-27 TRANSISTOR 2SD601A-Q
Q321 8-729-802-91 TRANSISTOR 2SD879
Q331 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q (E580)
Q332 8-729-900-51 TRANSISTOR DTA114TK (E580)
Q333 8-729-421-19 TRANSISTOR UN2213
< RESISTOR >
R260 1-216-043-91 RES, CHIP 560 5% 1/10W
R261 1-216-043-91 RES, CHIP 560 5% 1/10W
R262 1-216-295-91 SHORT 0
R263 1-216-295-91 SHORT 0
R264 1-216-295-91 SHORT 0
R265 1-216-295-91 SHORT 0
R266 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R267 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R268 1-216-081-00 METAL CHIP 22K 5% 1/10W
R269 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R270 1-216-081-00 METAL CHIP 22K 5% 1/10W
R271 1-216-049-91 RES, CHIP 1K 5% 1/10W
R272 1-216-081-00 METAL CHIP 22K 5% 1/10W
R273 1-216-081-00 METAL CHIP 22K 5% 1/10W
R274 1-216-073-00 METAL CHIP 10K 5% 1/10W
R275 1-216-073-00 METAL CHIP 10K 5% 1/10W
R276 1-216-049-91 RES, CHIP 1K 5% 1/10W
R288 1-216-097-91 RES, CHIP 100K 5% 1/10W
R317 1-216-079-00 METAL CHIP 18K 5% 1/10W
R321 1-216-017-91 RES, CHIP 47 5% 1/10W
R322 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
(EXCEPT E580)
R322 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
(E580)
R323 1-249-381-11 CARBON 1 5% 1/4W F
R324 1-216-180-00 RES, CHIP 180 5% 1/8W
R332 1-216-083-00 METAL CHIP 27K 5% 1/10W
(E580)
R333 1-249-394-11 CARBON 12 5% 1/4W F
(E580)
R335 1-216-073-00 METAL CHIP 10K 5% 1/10W
(E580)
R336 1-216-164-00 RES, CHIP 39 5% 1/8W
R337 1-216-164-00 RES, CHIP 39 5% 1/8W
R344 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
(EXCEPT E580)
R345 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(EXCEPT E580)
R346 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(EXCEPT E580)
R347 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(EXCEPT E580)
R348 1-216-033-00 METAL CHIP 220 5% 1/10W
(EXCEPT E580)
< TRANSFORMER >
T321 1-431-100-11 TRANSFORMER, BIAS OSCILLATION
T331 1-423-415-11 TRANSFORMER, BIAS OSCILLATION (E580)
* A-6791-504-A SE-68 BOARD, COMPLETE (E730B/E735B)
**********************
(Ref.No. 1,000 Series)
< CAPACITOR >
C970 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C971 1-124-257-00 ELECT 2.2uF 20% 50V
C972 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C973 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C974 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C975 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C976 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C977 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C978 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C979 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C980 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C981 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C982 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C983 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C984 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C985 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C986 1-126-157-11 ELECT 10uF 20% 16V
C987 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C988 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C991 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C992 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C993 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C994 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C995 1-126-157-11 ELECT 10uF 20% 16V
C996 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
< CONNECTOR >
CN970 1-573-825-11 CONNECTOR, BOARD TO BOARD 11P
< IC >
IC970 8-759-438-17 IC LA7337
< JUMPER RESISTOR >
JR970 1-216-296-91 SHORT 0
JR971 1-216-296-91 SHORT 0
JR972 1-216-296-91 SHORT 0
JR973 1-216-295-91 SHORT 0
JR974 1-216-295-91 SHORT 0
< COIL >
L970 1-414-933-11 INDUCTOR 6.8uH
L971 1-414-945-11 INDUCTOR 27uH
L972 1-414-938-21 INDUCTOR 47uH
L973 1-414-938-21 INDUCTOR 47uH
L975 1-414-934-21 INDUCTOR 10uH
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
