Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSISTOR >
Q970 8-729-216-22 TRANSISTOR 2SA1162
Q972 8-729-424-08 TRANSISTOR UN2111
Q973 8-729-422-27 TRANSISTOR 2SD601A-Q
Q974 8-729-422-27 TRANSISTOR 2SD601A-Q
Q975 8-729-424-08 TRANSISTOR UN2111
Q976 8-729-421-19 TRANSISTOR UN2213
< RESISTOR >
R969 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R970 1-216-085-00 METAL CHIP 33K 5% 1/10W
R971 1-216-085-00 METAL CHIP 33K 5% 1/10W
R973 1-216-081-00 METAL CHIP 22K 5% 1/10W
R974 1-216-081-00 METAL CHIP 22K 5% 1/10W
R975 1-216-295-91 SHORT 0
R976 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R977 1-216-089-91 RES, CHIP 47K 5% 1/10W
R978 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R979 1-216-073-00 METAL CHIP 10K 5% 1/10W
R980 1-216-097-91 RES, CHIP 100K 5% 1/10W
R981 1-216-083-00 METAL CHIP 27K 5% 1/10W
R982 1-216-089-91 RES, CHIP 47K 5% 1/10W
R983 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R985 1-216-041-00 METAL CHIP 470 5% 1/10W
R986 1-216-089-91 RES, CHIP 47K 5% 1/10W
R988 1-216-083-00 METAL CHIP 27K 5% 1/10W
R989 1-216-049-91 RES, CHIP 1K 5% 1/10W
R990 1-216-295-91 SHORT 0
R993 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R994 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R995 1-216-073-00 METAL CHIP 10K 5% 1/10W
R996 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R997 1-216-073-00 METAL CHIP 10K 5% 1/10W
R998 1-216-073-00 METAL CHIP 10K 5% 1/10W
R999 1-216-295-91 SHORT 0
1-468-270-11 SR-825 BLOCK (Ref.No. 3,000Series)
************
< CAPACITOR >
C151 9-980-236-01 ELECT 47uF 400V
C153 1-126-967-11 ELECT 47uF 50V
C154 1-126-960-11 ELECT 1uF 50V
C201 1-126-934-11 ELECT 220uF 16V
C202 1-126-925-11 ELECT 470uF 10V
C203 1-126-934-11 ELECT 220uF 16V
C204 1-126-933-11 ELECT 100uF 16V
C205 1-126-965-11 ELECT 22uF 50V
C206 1-126-947-11 ELECT 47uF 35V
C207 1-126-965-11 ELECT 22uF 50V
C208 1-126-925-11 ELECT 470uF 10V
C251 1-126-967-11 ELECT 47uF 50V
C252 1-126-183-11 ELECT 1000uF 16V
C253 1-126-927-11 ELECT 2200uF 10V
C254 1-126-935-11 ELECT 470uF 16V
< DIODE >
D151 8-719-043-74 DIODE AK04
D153 8-719-911-19 DIODE 1SS119
D154 8-719-043-74 DIODE AK04
D155 9-900-535-01 DIODE AU02Z
D203 8-719-109-85 DIODE RD5.1ES
D204 8-719-911-19 DIODE 1SS119
D205 8-719-911-19 DIODE 1SS119
D251 9-900-535-01 DIODE AU02Z
D252 8-719-510-73 DIODE S3L20U
D253 8-719-027-20 DIODE D3S4M
D254 9-900-535-01 DIODE AU02Z
< FUSE >
! F101 1-532-388-31 FUSE (T2AL/250V)
< IC >
! IC151 9-980-235-01 IC AN8028
! IC201 8-759-438-18 IC PD12RD08
< PHOTO COUPLER >
! PC151 8-749-924-80 COUPLER, PHOTO PS2561
< IC LINK >
! PS201 1-533-592-21 LINK, IC 49101.6 (1.6A)
! PS202 1-533-593-21 LINK, IC 491002 (2A)
! PS251 1-533-589-11 LINK, IC 491.750 (750mA)
< TRANSISTOR >
! Q201 8-729-113-32 TRANSISTOR 2SB733
Q205 8-729-019-01 TRANSISTOR 2SD2394
Q206 8-729-119-78 TRANSISTOR 2SC2785
Q207 8-729-177-32 TRANSISTOR 2SD773
Q211 8-729-422-72 TRANSISTOR UN4211
< RESISTOR >
R252 9-980-233-01 FUSIBLE 0.47 1/4W
MISCELLANEOUS
***************
10 1-783-166-11 CABLE, FLAT (FFM-17)
16 1-762-844-31 SWITCH, ROTARY (CLICK SHUTTLE) (E580)
27 1-783-169-11 CABLE, FLAT (FFD-2)
! 55 1-782-012-11 CORD, POWER
59 1-779-725-11 BOARD TO BOARD (5P) CONNECTOR
704 1-500-144-11 HEAD, FE
721 A-6759-620-A HEAD BLOCK ASSY, ACE (ALPS) EURO
768 1-759-371-11 DRUM ASSY (DZH-85A-R) (E580)
768 1-759-373-11 DRUM ASSY (DZH-86A-R)
(EXCEPT E580/E730B/E735B)
768 1-759-557-11 DRUM ASSY (DZH-98A-R) (E730B/E735B)
M902 1-698-971-11 MOTOR, DC (CAPSTAN)
M903 X-3947-577-1 MOTOR ASSY, CAM
SE-68 SR-825
