– 80 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D103 8-719-016-74 DIODE 1SS352
D104 8-719-016-74 DIODE 1SS352
D107 8-719-046-39 DIODE SEL5821A-TH15
(SURROUND FIELD ON/OFF)
D108 8-719-313-45 DIODE SEL6810A-TH10 (CURSOR SUR)
D109 8-719-313-45 DIODE SEL6810A-TH10 (CURSOR EQ)
D110 8-719-313-45 DIODE SEL6810A-TH10 (CURSOR INDEX)
D111 8-719-064-55 DIODE SEC1803C (PHONO)
D112 8-719-064-55 DIODE SEC1803C (TUNER)
D113 8-719-064-55 DIODE SEC1803C (CD)
D114 8-719-064-55 DIODE SEC1803C (MD/DAT)
D115 8-719-064-55 DIODE SEC1803C (TAPE)
D116 8-719-064-56 DIODE SEC2484C (TV/DBS (TV/LD))
D117 8-719-064-56 DIODE SEC2484C (DVD/LD (DVD))
D118 8-719-064-56 DIODE SEC2484C (VIDEO3)
D119 8-719-064-56 DIODE SEC2484C (VIDEO2)
D120 8-719-064-56 DIODE SEC2484C (VIDEO1)
D121 8-719-313-45 DIODE SEL6810A-TH10 (BASS BOOST)
D124 8-719-059-14 DIODE SID313BP-TP19
D125 8-719-059-14 DIODE SID313BP-TP19
D126 8-719-016-74 DIODE 1SS352
D127 8-719-016-74 DIODE 1SS352
D128 8-719-064-57 DIODE SID5K23CTP15
D129 8-719-801-78 DIODE 1SS184
D913 8-719-977-81 DIODE DTZ33B
< FLUORESCENT INDICATOR >
FL101 1-517-781-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC101 8-759-459-86 IC NJL64H400A
IC102 8-759-586-43 IC MB90553APF-G-139-BND
IC103 8-759-823-87 IC LB1638M
IC104 8-759-075-35 IC TD62C950RF
IC105 8-759-389-51 IC MSC1164GS-KR1
IC106 8-759-545-07 IC TMP87C447U-4A06
IC107 8-759-235-19 IC TC74HC08AF(EL)
< JUMPER RESISTOR >
JW21 1-216-295-91 SHORT 0 (DA333ES)
JW22 1-216-295-91 SHORT 0 (DA555ES)
< COIL >
L101 1-500-425-11 FERRITE 0uH
< TRANSISTOR >
Q101 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q102 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q103 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q104 8-729-230-49 TRANSISTOR 2SC2712-YG
Q105 8-729-230-49 TRANSISTOR 2SC2712-YG
Q106 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q107 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q108 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q109 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q110 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q111 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q112 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q113 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q114 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q115 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q116 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q118 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q119 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q120 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q121 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q122 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q123 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q124 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q125 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q126 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q127 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q128 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q129 8-729-010-35 TRANSISTOR MSD602-RT1
Q130 8-729-010-35 TRANSISTOR MSD602-RT1
Q971 8-729-822-05 TRANSISTOR 2SD1622-ST-TD
< RESISTOR >
R101 1-219-163-11 RES,CHIP 1.1 5% 1/10W
R103 1-216-089-91 RES,CHIP 47K 5% 1/10W
R105 1-216-001-00 METAL CHIP 10 5% 1/10W
R106 1-216-001-00 METAL CHIP 10 5% 1/10W
R107 1-216-001-00 METAL CHIP 10 5% 1/10W
R108 1-216-097-91 RES,CHIP 100K 5% 1/10W
R109 1-216-097-91 RES,CHIP 100K 5% 1/10W
R110 1-216-073-00 METAL CHIP 10K 5% 1/10W
R111 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R112 1-216-073-00 METAL CHIP 10K 5% 1/10W
R113 1-216-073-00 METAL CHIP 10K 5% 1/10W
R114 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R115 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-073-00 METAL CHIP 10K 5% 1/10W
R117 1-216-081-00 METAL CHIP 22K 5% 1/10W
R118 1-216-081-00 METAL CHIP 22K 5% 1/10W
R119 1-216-049-91 RES,CHIP 1K 5% 1/10W
R120 1-216-049-91 RES,CHIP 1K 5% 1/10W
R121 1-216-049-91 RES,CHIP 1K 5% 1/10W
R122 1-216-073-00 METAL CHIP 10K 5% 1/10W
R123 1-216-049-91 RES,CHIP 1K 5% 1/10W
R124 1-216-029-00 METAL CHIP 150 5% 1/10W
R125 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R126 1-216-073-00 METAL CHIP 10K 5% 1/10W
R127 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R128 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R129 1-216-049-91 RES,CHIP 1K 5% 1/10W
R130 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R131 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R132 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R133 1-216-037-00 METAL CHIP 330 5% 1/10W
R134 1-216-037-00 METAL CHIP 330 5% 1/10W
R135 1-216-033-00 METAL CHIP 220 5% 1/10W
R136 1-216-037-00 METAL CHIP 330 5% 1/10W
R137 1-216-037-00 METAL CHIP 330 5% 1/10W
DISPLAY
