Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
ENCODER
R138 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R139 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R140 1-216-037-00 METAL CHIP 330 5% 1/10W
R141 1-216-041-00 METAL CHIP 470 5% 1/10W
R142 1-216-045-00 METAL CHIP 680 5% 1/10W
R143 1-216-049-91 RES,CHIP 1K 5% 1/10W
R144 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R145 1-216-037-00 METAL CHIP 330 5% 1/10W
R146 1-216-041-00 METAL CHIP 470 5% 1/10W
R147 1-216-045-00 METAL CHIP 680 5% 1/10W
R148 1-216-049-91 RES,CHIP 1K 5% 1/10W
R149 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R150 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-041-00 METAL CHIP 470 5% 1/10W
R153 1-216-045-00 METAL CHIP 680 5% 1/10W
R154 1-216-037-00 METAL CHIP 330 5% 1/10W
R161 1-216-049-91 RES,CHIP 1K 5% 1/10W
R162 1-216-049-91 RES,CHIP 1K 5% 1/10W
R163 1-216-073-00 METAL CHIP 10K 5% 1/10W
R164 1-216-097-91 RES,CHIP 100K 5% 1/10W
R165 1-216-073-00 METAL CHIP 10K 5% 1/10W
R166 1-216-097-91 RES,CHIP 100K 5% 1/10W
R167 1-216-302-00 METAL CHIP 2.7 5% 1/10W
R168 1-216-049-91 RES,CHIP 1K 5% 1/10W
R169 1-216-049-91 RES,CHIP 1K 5% 1/10W
R170 1-216-049-91 RES,CHIP 1K 5% 1/10W
R171 1-216-049-91 RES,CHIP 1K 5% 1/10W
R172 1-216-049-91 RES,CHIP 1K 5% 1/10W
R173 1-216-097-91 RES,CHIP 100K 5% 1/10W
R177 1-216-073-00 METAL CHIP 10K 5% 1/10W
R915 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
RR10 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
RR20 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
RR21 1-216-037-00 METAL CHIP 330 5% 1/10W
RR22 1-216-041-00 METAL CHIP 470 5% 1/10W
(DA555ES)
< SWITCH >
S103 1-572-184-11 SWITCH, KEYBOARD (INPUT MODE)
S104 1-572-184-11 SWITCH, KEYBOARD (SLEEP)
S105 1-572-184-11 SWITCH, KEYBOARD (DIMMER)
S106 1-572-184-11 SWITCH, KEYBOARD (TUNING +)
S107 1-572-184-11 SWITCH, KEYBOARD (TUNING -)
S108 1-572-184-11 SWITCH, KEYBOARD (FM MODE)
S109 1-572-184-11 SWITCH, KEYBOARD (DOWN)
S110 1-572-184-11 SWITCH, KEYBOARD (UP)
S111 1-572-184-11 SWITCH, KEYBOARD (LEFT)
S112 1-572-184-11 SWITCH, KEYBOARD (CURSOR MODE)
S113 1-572-184-11 SWITCH, KEYBOARD (EQUALIZER)
S114 1-572-184-11 SWITCH, KEYBOARD (MODE)
S115 1-572-184-11 SWITCH, KEYBOARD (GENRE)
S116 1-572-184-11 SWITCH, KEYBOARD (BASS BOOST)
S117 1-572-184-11 SWITCH, KEYBOARD (RIGHT)
S118 1-572-184-11 SWITCH, KEYBOARD (SET UP)
S119 1-572-184-11 SWITCH, KEYBOARD (SOUND FIELD ON/OFF)
S120 1-572-184-11 SWITCH, KEYBOARD (MEMORY)
S121 1-572-184-11 SWITCH, KEYBOARD (DISPLAY)
< TRANSFORMER >
T902 1-431-387-11 TRANSFORMER, POWER (DA555ES)
< VIBRATOR >
X101 1-767-359-11 VIBRATOR, CERAMIC (4MHz)
X102 1-767-938-21 VIBRATOR, CERAMIC (7.28MHz)
**************************************************************
* 1-670-146-11 ENCODER BOARD
*************
< CONNECTOR >
CNP101 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D123 8-719-313-45 DIODE SEL6810A-TH10
< RESISTOR >
R102 1-249-411-11 CARBON 330 5% 1/4W
R159 1-249-417-11 CARBON 1K 5% 1/4W F
R160 1-249-419-11 CARBON 1.5K 5% 1/4W F
< VARIABLE RESISTOR >
RV101 1-467-808-21 ENCODER, ROTARY
< SWITCH >
S126 1-572-184-11 SWITCH, KEYBOARD (MODE)
S127 1-572-184-11 SWITCH, KEYBOARD (MUTING)
**************************************************************
* 1-670-145-11 FRONT VIDEO BOARD
*****************
< CAPACITOR >
C299 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN804 1-564-725-11 PIN, CONNECTOR (SMALL TYPE) 9P
< JACK >
J809 1-784-808-11 TERMINAL, S (S VIDEO3)
J810 1-779-798-11 JACK, PIN (BLOCK) (L TYPE) 3P
(VIDEO3/AUDIO3)
< RESISTOR >
R890 1-249-417-11 CARBON 1K 5% 1/4W F
R891 1-249-417-11 CARBON 1K 5% 1/4W F
R892 1-247-804-11 CARBON 75 5% 1/4W
R893 1-247-804-11 CARBON 75 5% 1/4W
R894 1-247-804-11 CARBON 75 5% 1/4W
**************************************************************
FRONT VIDEODISPLAY
