– 82 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
* 1-670-139-11 HP BOARD
********
< JACK >
J701 1-568-519-41 JACK, LARGE TYPE (PHONES)
************************************************************
* 1-670-147-11 LED BOARD
*********
< CAPACITOR >
C128 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< DIODE >
D122 8-719-070-83 DIODE SELU5E20C-TP15 (DOLBY DIGITAL)
< RESISTOR >
R174 1-216-073-00 METAL CHIP 10K 5% 1/10W
**************************************************************
A-4419-732-A MAIN BOARD, COMPLETE (DA555ES)
********************
A-4419-736-A MAIN BOARD, COMPLETE (DA333ES)
********************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C201 1-126-047-81 ELECT 4.7uF 20% 50V
C203 1-162-283-31 CERAMIC 120PF 10% 50V
C204 1-124-995-11 ELECT 220uF 20% 10V
C205 1-125-896-91 MYLAR 0.0091uF 5% 50V
C206 1-136-159-00 FILM 0.033uF 5% 50V
C207 1-126-045-11 ELECT 2.2uF 20% 50V
C208 1-126-009-81 ELECT 100uF 20% 16V
C211 1-126-021-11 ELECT 33uF 20% 25V
C216 1-126-021-11 ELECT 33uF 20% 25V
C217 1-126-008-51 ELECT 47uF 20% 16V
C224 1-101-810-00 CERAMIC 100PF 5% 500V
C225 1-162-294-31 CERAMIC 0.001uF 10% 50V
C248 1-126-009-81 ELECT 100uF 20% 16V
C249 1-126-009-81 ELECT 100uF 20% 16V
C251 1-126-047-81 ELECT 4.7uF 20% 50V
C253 1-162-283-31 CERAMIC 120PF 10% 50V
C254 1-124-995-11 ELECT 220uF 20% 10V
C255 1-125-896-91 MYLAR 0.0091uF 5% 50V
C256 1-136-159-00 FILM 0.033uF 5% 50V
C257 1-126-045-11 ELECT 2.2uF 20% 50V
C258 1-126-009-81 ELECT 100uF 20% 16V
C261 1-126-021-11 ELECT 33uF 20% 25V
C266 1-126-021-11 ELECT 33uF 20% 25V
C267 1-126-008-51 ELECT 47uF 20% 16V
C274 1-101-810-00 CERAMIC 100PF 5% 500V
C275 1-162-294-31 CERAMIC 0.001uF 10% 50V
C297 1-162-294-31 CERAMIC 0.001uF 10% 50V
C351 1-126-009-81 ELECT 100uF 20% 16V
C352 1-126-009-81 ELECT 100uF 20% 16V
C353 1-162-294-31 CERAMIC 0.001uF 10% 50V
C401 1-124-994-11 ELECT 100uF 20% 10V
C402 1-124-994-11 ELECT 100uF 20% 10V
C403 1-124-994-11 ELECT 100uF 20% 10V
C404 1-162-199-31 CERAMIC 10PF 5% 50V
C405 1-162-199-31 CERAMIC 10PF 5% 50V
C406 1-162-199-31 CERAMIC 10PF 5% 50V
C407 1-126-021-11 ELECT 33uF 20% 25V
C408 1-126-021-11 ELECT 33uF 20% 25V
C409 1-126-021-11 ELECT 33uF 20% 25V
C410 1-126-021-11 ELECT 33uF 20% 25V
C411 1-126-021-11 ELECT 33uF 20% 25V
C412 1-126-021-11 ELECT 33uF 20% 25V
C413 1-126-021-11 ELECT 33uF 20% 25V
C414 1-102-508-91 CERAMIC 10PF 0.5PF 50V
C415 1-126-021-11 ELECT 33uF 20% 25V
C416 1-102-508-91 CERAMIC 10PF 0.5PF 50V
C451 1-124-994-11 ELECT 100uF 20% 10V
C452 1-124-994-11 ELECT 100uF 20% 10V
C453 1-124-994-11 ELECT 100uF 20% 10V
C454 1-162-199-31 CERAMIC 10PF 5% 50V
C455 1-162-199-31 CERAMIC 10PF 5% 50V
C456 1-162-199-31 CERAMIC 10PF 5% 50V
C457 1-126-021-11 ELECT 33uF 20% 25V
C458 1-126-021-11 ELECT 33uF 20% 25V
C459 1-126-021-11 ELECT 33uF 20% 25V
C460 1-126-021-11 ELECT 33uF 20% 25V
C461 1-126-021-11 ELECT 33uF 20% 25V
C462 1-126-021-11 ELECT 33uF 20% 25V
C463 1-126-021-11 ELECT 33uF 20% 25V
C464 1-102-508-91 CERAMIC 10PF 0.5PF 50V
C494 1-126-008-51 ELECT 47uF 20% 16V
C495 1-126-008-51 ELECT 47uF 20% 16V
C501 1-126-047-81 ELECT 4.7uF 20% 50V
C502 1-162-283-31 CERAMIC 120PF 10% 50V
C503 1-124-995-11 ELECT 220uF 20% 10V
C504 1-102-233-00 CERAMIC 33PF 10% 500V
C505 1-102-934-00 CERAMIC 1.0PF ±0.25PF 50V
C514 1-102-936-00 CERAMIC 3.0PF ±0.25PF 50V
C520 1-126-008-51 ELECT 47uF 20% 16V
C521 1-107-597-11 CERAMIC 22PF 10% 500V
C522 1-107-597-11 CERAMIC 22PF 10% 500V
C523 1-162-286-31 CERAMIC 220PF 10% 50V
C524 1-136-157-00 FILM 0.022uF 5% 50V
C525 1-124-997-11 ELECT 470uF 20% 6.3V
C526 1-126-049-11 ELECT 22uF 20% 50V
C529 1-130-475-00 MYLAR 0.0022uF 5% 50V
C530 1-130-475-00 MYLAR 0.0022uF 5% 50V
C551 1-126-047-81 ELECT 4.7uF 20% 50V
C552 1-162-283-31 CERAMIC 120PF 10% 50V
C553 1-124-995-11 ELECT 220uF 20% 10V
C554 1-102-233-00 CERAMIC 33PF 10% 500V
C555 1-102-934-00 CERAMIC 1.0PF ±0.25PF 50V
C564 1-102-936-00 CERAMIC 3.0PF ±0.25PF 50V
C570 1-126-008-51 ELECT 47uF 20% 16V
C571 1-107-597-11 CERAMIC 22PF 10% 500V
LEDHP
