– 83 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
C572 1-107-597-11 CERAMIC 22PF 10% 500V
C573 1-162-286-31 CERAMIC 220PF 10% 50V
C574 1-136-157-00 FILM 0.022uF 5% 50V
C579 1-130-475-00 MYLAR 0.0022uF 5% 50V
C580 1-130-475-00 MYLAR 0.0022uF 5% 50V
C598 1-126-077-11 ELECT 100uF 20% 100V
C599 1-126-077-11 ELECT 100uF 20% 100V
C601 1-126-047-81 ELECT 4.7uF 20% 50V
C602 1-162-283-31 CERAMIC 120PF 10% 50V
C603 1-124-995-11 ELECT 220uF 20% 10V
C604 1-102-233-00 CERAMIC 33PF 10% 500V
C605 1-102-934-00 CERAMIC 1.0PF ±0.25PF 50V
C614 1-102-936-00 CERAMIC 3.0PF ±0.25PF 50V
C620 1-126-008-51 ELECT 47uF 20% 16V
C621 1-107-597-11 CERAMIC 22PF 10% 500V
C622 1-107-597-11 CERAMIC 22PF 10% 500V
C623 1-162-286-31 CERAMIC 220PF 10% 50V
C624 1-136-157-00 FILM 0.022uF 5% 50V
C629 1-130-475-00 MYLAR 0.0022uF 5% 50V
C630 1-130-475-00 MYLAR 0.0022uF 5% 50V
C651 1-126-047-81 ELECT 4.7uF 20% 50V
C652 1-162-283-31 CERAMIC 120PF 10% 50V
C653 1-124-995-11 ELECT 220uF 20% 10V
C654 1-102-233-00 CERAMIC 33PF 10% 500V
C664 1-102-936-00 CERAMIC 3.0PF ±0.25PF 50V
C951 1-136-153-00 FILM 0.01uF 5% 50V
C952 1-136-153-00 FILM 0.01uF 5% 50V
C953 1-126-041-11 ELECT 2200uF 20% 35V
C954 1-126-041-11 ELECT 2200uF 20% 35V
C955 1-126-026-11 ELECT 470uF 20% 25V
C956 1-126-026-11 ELECT 470uF 20% 25V
C960 1-119-796-21 ELECT 4700uF 20% 16V
C961 1-119-841-11 ELECT 1000uF 20% 63V
C962 1-126-012-11 ELECT 470uF 20% 16V
C963 1-164-159-11 CERAMIC 0.1uF 50V
C965 1-136-153-00 FILM 0.01uF 5% 50V
C966 1-136-153-00 FILM 0.01uF 5% 50V
C991 1-126-040-11 ELECT 1000uF 20% 35V
C992 1-107-913-11 ELECT 470uF 20% 35V
(DA555ES)
C993 1-126-044-11 ELECT 1uF 20% 50V
(DA555ES)
< CONNECTOR >
CNP502 1-779-978-11 PIN, CONNECTOR 3P
CNP601 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CNP911 1-779-978-11 PIN, CONNECTOR 3P
CNP951 1-785-102-11 PIN, CONNECTOR 4P
CNP952 1-785-103-11 PIN, CONNECTOR 5P
CNP992 1-764-326-11 PIN, CONNECTOR (PCB)(V TYPE) 3P(DA555ES)
CNS409 1-569-323-11 SOCKET, CONNECTOR 19P
CNV501 1-785-104-11 PIN, CONNECTOR 6P
< DIODE >
D301 8-719-911-19 DIODE 1SS119-25
D302 8-719-911-19 DIODE 1SS119-25
D303 8-719-911-19 DIODE 1SS119-25
D351 8-719-911-19 DIODE 1SS119-25
D352 8-719-911-19 DIODE 1SS119-25
D353 8-719-911-19 DIODE 1SS119-25
D401 8-719-911-19 DIODE 1SS119-25
D501 8-719-911-19 DIODE 1SS119-25
D502 8-719-911-19 DIODE 1SS119-25
D503 8-719-109-51 DIODE RD2.0ES-B2
D504 8-719-911-19 DIODE 1SS119-25
D505 8-719-911-19 DIODE 1SS119-25
D506 8-719-911-19 DIODE 1SS119-25
D507 8-719-911-19 DIODE 1SS119-25
D547 8-719-911-19 DIODE 1SS119-25
D548 8-719-911-19 DIODE 1SS119-25
D549 8-719-911-19 DIODE 1SS119-25
D551 8-719-911-19 DIODE 1SS119-25
D552 8-719-911-19 DIODE 1SS119-25
D553 8-719-109-51 DIODE RD2.0ES-B2
D554 8-719-911-19 DIODE 1SS119-25
D555 8-719-911-19 DIODE 1SS119-25
D601 8-719-911-19 DIODE 1SS119-25
D602 8-719-911-19 DIODE 1SS119-25
D603 8-719-109-51 DIODE RD2.0ES-B2
D604 8-719-911-19 DIODE 1SS119-25
D605 8-719-911-19 DIODE 1SS119-25
D655 8-719-911-19 DIODE 1SS119-25
D951 8-719-024-99 DIODE 11ES2-NTA2B
D952 8-719-024-99 DIODE 11ES2-NTA2B
D953 8-719-024-99 DIODE 11ES2-NTA2B
D954 8-719-024-99 DIODE 11ES2-NTA2B
D955 8-719-025-03 DIODE RBA-402-SL
D991 8-719-024-99 DIODE 11ES2-NTA2B
D992 8-719-024-99 DIODE 11ES2-NTA2B
< GROUND PLATE >
* EP902 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F951 1-533-614-11 FUSE, GLASS CYLLINDERICAL (1.6A/125V)
! F952 1-533-614-11 FUSE, GLASS CYLLINDERICAL (1.6A/125V)
! F953 1-533-690-11 FUSE, GLASS CYLLINDERICAL (DIA.5)
(3.15A/125V)
< FUSE HOLDER >
FH901 1-533-217-31 HOLDER, FUSE
FH902 1-533-217-31 HOLDER, FUSE
FH903 1-533-217-31 HOLDER, FUSE
FH951 1-533-217-31 HOLDER, FUSE
FH952 1-533-217-31 HOLDER, FUSE
FH953 1-533-217-31 HOLDER, FUSE
< IC >
IC201 8-759-636-74 IC M5218AP-22
IC202 8-759-805-13 IC LC7821
IC204 8-759-636-74 IC M5218AP-22
IC351 8-759-805-14 IC LC7822
IC401 8-759-636-74 IC M5218AP-22
IC402 8-759-636-74 IC M5218AP-22
IC405 8-759-636-74 IC M5218AP-22
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
