STR-DA5400ES
127
IC Pin Function Description
DIGITAL BOARD IC2003 EP2C5T144C8N (FIELD PROGRAMMABLE GATE ARRAY)
Pin No. Pin Name I/O Description
1
ASDO
O AS data output to the ash memory
2
nCSO
O Chip select signal output to the ash memory
3 MUTEOUT O Muting control signal output terminal
4 AMCKOUT O Audio master clock signal output to the D/A converter (foe audio section)
5 VCCIO1 - Power supply terminal (+3.3V)
6 GND - Ground terminal
7 LRCKOUT O L/R sampling clock signal output for PCM audio signal to the lip sync adjust
8 - - Not used
9 BCKOUT O Bit clock signal output for PCM audio signal to the lip sync adjust
10
TDO
O Data output terminal (for JTAG) Not used
11
TMS
I Mode selection signal input terminal (for JTAG) Not used
12
TCK
I Clock signal input terminal (for JTAG) Not used
13
TDI
I Data input terminal (for JTAG) Not used
14
DATA0
I Data input from the ash memory
15
DCLK
O Clock signal output to the ash memory
16
nCE
I Chip enable signal input terminal Not used
17 MCLKIN I Master clock signal input from the digital audio interface receiver or HDMI receiver
18 BCKIN I Bit clock signal input for PCM audio signal from the DSP2
19 GND - Ground terminal
20
nCONFIG
I Con guration control signal input terminal Not used
21 XRESET I Reset signal input from the system controller "L": reset
22 AMCKIN I Audio master clock signal input terminal
23 VCCIO1 - Power supply terminal (+3.3V)
24 SD0OUT O PCM audio signal (front L/R) output to the lip sync adjust
25 SD1OUT O PCM audio signal (surround L/R) output to the lip sync adjust
26 - - Not used
27 SD2OUT O PCM audio signal (center, sub woofer) output to the lip sync adjust
28 SD3OUT O PCM audio signal (surround back L/R) output to the lip sync adjust
29 VCCIO1 - Power supply terminal (+3.3V)
30 - - Not used
31 LRCKIN I L/R sampling clock signal input for PCM audio signal from the DSP2
32 - - Not used
33 GND - Ground terminal
34 GND_PLL1 - Ground terminal (for PLL)
35 VCCD_PLL1 - Power supply terminal (+1.2V) (digital system) (for PLL)
36 GND_PLL1 - Ground terminal (for PLL)
37 VCCA_PLL1 - Power supply terminal (+1.2V) (analog system) (for PLL)
38 GNDA_PLL1 - Ground terminal (analog system) (for PLL)
39 GND - Ground terminal
40 SD0IN I PCM audio signal (front L/R) input from the DSP2
41 - - Not used
42 SD1IN I PCM audio signal (surround L/R) input from the DSP2
43 SD2IN I PCM audio signal (center, sub woofer) input from the DSP2
44 - - Not used
45 SD3IN I PCM audio signal (surround back L/R) input from the DSP2
46 VCCIO4 - Power supply terminal (+3.3V)
47 I2CADRS0 - Not used
48 I2CADRD1 - Not used
49 GND - Ground terminal
50 VCCINT - Power supply terminal (+1.2V)
51 SDRAM - Not used
52, 53 - - Not used
54 VCCIO4 - Power supply terminal (+3.3V)
