Pin No. Pin Name I/O Description
A1 CLKCFG0 I Clock frequency setting terminal
A2 XTAL O System clock output terminal (12.288 MHz)
A3 TMS I Mode selection signal input terminal (for JTAG) Not used
A4 TCK I Clock signal input terminal (for JTAG) Not used
A5 TDI I Data input terminal (for JTAG) Not used
A6 CLKOUT O Clock signal output terminal Not used
A7 TDO O Data output terminal (for JTAG) Not used
A8 EMU - Not used
A9 MOSI I Serial data input from the DSP controller
A10 MISO O Serial data output to the DSP controller
A11 SPIDS I Serial data latch pulse signal input from the DSP controller
A12 VDDINT - Power supply terminal (+1.2V)
A13, A14 GND - Ground terminal
B1 CLKCFG1 I Clock frequency setting terminal
B2 GND - Ground terminal
B3 VDDEXT - Power supply terminal (+3.3V)
B4 CLKIN I System clock input terminal (12.288 MHz)
B5 TRST I Reset signal input terminal (for JTAG) Not used
B6 AVSS - Ground terminal
B7 AVDD - Power supply terminal (+1.2V)
B8 VDDEXT - Power supply terminal (+3.3V)
B9 SPICLK I Serial data transfer clock signal input from the DSP controller
B10 RESET I Reset signal input from the DSP controller "L": reset
B11 VDDINT - Power supply terminal (+1.2V)
B12 to B14 GND - Ground terminal
C1, C2
BOOTCFG1,
BOOTCFG0
I Boot mode setting signal input from the DSP controller
C3, C12,
C13
GND - Ground terminal
C14, D1 VDDINT - Power supply terminal (+1.2V)
D2,
D4 to D6,
D9 to D11,
D13
GND - Ground terminal
D14, E1 VDDINT - Power supply terminal (+1.2V)
E2,
E4 to E6,
E9 to E11,
E13
GND - Ground terminal
E14 P_ERROR O PLL lock error signal and data error fl ag output to the DSP2 and DSP controller
F1 FLAG1 I Audio muting control signal input from the digital audio interface receiver or HDMI receiver
F2 FLAG0 O Interrupt request signal output to the DSP controller
F4 to F6,
F9 to F11
GND - Ground terminal
F13 NONAUDIO I PCM audio data input from the digital audio interface receiver or video system controller
F14 DPFSCK I Master clock signal input from the digital audio processor1 or HDMI receiver
G1 AD7 I/O
Two-way data bus with fl ash memory and S-RAM
Address signal output to the address latch
G2 VDDINT - Power supply terminal (+1.2V)
G13 VDDEXT - Power supply terminal (+3.3V)
G14 DPBCK I
Bit clock signal input for PCM audio signal input from the digital audio interface receiver or
HDMI receiver.
H1 AD6 I/O
Two-way data bus with fl ash memory and S-RAM
Address signal output to the address latch
H2 VDDEXT - Power supply terminal (+3.3V)
H13 DPLRCK I
L/R sampling clock signal input for PCM audio signal input from the digital audio interface
receiver or HDMI receiver
H14 DPDVBCK O Bit clock signal output for PCM audio signal output to the DSP2
