STR-DA5400ES
129
Pin No. Pin Name I/O Description
118, 119 D2, D3 I/O Two-way data bus with the SD-RAM
120 - - Not used
121, 122 D4, D5 I/O Two-way data bus with the SD-RAM
123 GND - Ground terminal
124 VCCINT - Power supply terminal (+1.2V)
125, 126 D6, D7 I/O Two-way data bus with the SD-RAM
127 VCCIO2 - Power supply terminal (+3.3V)
128 GND - Ground terminal
129 D8 I/O Two-way data bus with the SD-RAM
130 GND - Ground terminal
131 VCCINT - Power supply terminal (+1.2V)
132 to 134 D9 to D11 I/O Two-way data bus with the SD-RAM
135 - - Not used
136, 137 D12, D13 I/O Two-way data bus with the SD-RAM
138 VCCIO2 - Power supply terminal (+3.3V)
139 D14 I/O Two-way data bus with the SD-RAM
140 GND - Ground terminal
141 D15 I/O Two-way data bus with the SD-RAM
142 UNQM O Data mask signal output to the SD-RAM (upper byte)
143 CLK O Clock signal output to the SD-RAM
144 CKE O Clock enable signal output to the SD-RAM
