STR-DA5400ES
137
Pin No. Pin Name I/O Description
1 to 3 Q10 to Q8 O Serial data output to the HDMI transmitter and video processor1
4 IOGND - Ground terminal
5 ODCK O Output data clock signal output to the clock generator
6 IOVCC33 - Power supply terminal (+3.3V)
7 to 10 Q7 to Q4 O Serial data output to the HDMI transmitter and video processor1
11 CGND - Ground terminal
12 CVCC18 - Power supply terminal (+1.8V)
13, 14 Q3, Q2 O Serial data output to the HDMI transmitter and video processor1
15, 16 Q1, Q0 O Serial data output to the HDMI transmitter
17 IOGND - Ground terminal
18 IOVCC33 - Power supply terminal (+3.3V)
19 DE O Data enable signal output to the HDMI transmitter and video processor1
20 HSYNC O Horizontal sync signal output to the HDMI transmitter and video processor1
21 VSYNC O Vertical sync signal output to the HDMI transmitter and video processor1
22 EVNODD - Not used
23 CGND - Ground terminal
24, 25 CVCC18 - Power supply terminal (+1.8V)
26 CSDA I/O
I2C data bus with the EEPROM, HDMI transmitter, video system controller and D/A converter
(for video section),
27 CSCL I I2C clock signal input from the video system controller
28 DSDA1 I/O I2C data bus with the HDMI input selector and EEPROM
29 DSCL1 I I2C clock signal input from the HDMI input selector
30 R1PWR5V I Power supply voltage (+5V) input from the HDMI connector
31 IOGND - Ground terminal
32 IOVCC33 - Power supply terminal (+3.3V)
33 DSDA0 I/O I2C data bus with the HDMI input selector and EEPROM
34 DSCL0 I I2C clock signal input from the HDMI input selector
35 R0PWR5V I Power supply voltage (+5V) input from the HDMI connector
36 AGND - Ground terminal
37 AVCC18 - Power supply terminal (+1.8V)
38 AVCC33 - Power supply terminal (+3.3V)
39 R0XC- I TMDS clock (negative) signal input from the HDMI input selector
40 R0XC+ I TMDS clock (positive) signal input from the HDMI input selector
41 AGND - Ground terminal
42 AVCC33 - Power supply terminal (+3.3V)
43 R0X0- I TMDS data (negative) input from the HDMI input selector
44 R0X0+ I TMDS data (positive) input from the HDMI input selector
45 AGND - Ground terminal
46 AVCC33 - Power supply terminal (+3.3V)
47 R0X1- I TMDS data (negative) input from the HDMI input selector
48 R0X1+ I TMDS data (positive) input from the HDMI input selector
49 AGND - Ground terminal
50 AVCC33 - Power supply terminal (+3.3V)
51 R0X2- I TMDS data (negative) input from the HDMI input selector
52 R0X2+ I TMDS data (positive) input from the HDMI input selector
53 AGND - Ground terminal
54 AVCC18 - Power supply terminal (+1.8V)
55 RSVDNC - Not used
56 AVCC33 - Power supply terminal (+3.3V)
57 R1XC- I TMDS clock (negative) signal input from the HDMI input selector
58 R1XC+ I TMDS clock (positive) signal input from the HDMI input selector
59 AGND - Ground terminal
60 AVCC33 - Power supply terminal (+3.3V)
61 R1X0- I TMDS data (negative) input from the HDMI input selector
62 R1X0+ I TMDS data (positive) input from the HDMI input selector
D VIDEO BOARD IC3511 SII9135CTU (HDMI RECEIVER)
