STR-DA5400ES
138
Pin No. Pin Name I/O Description
63 AGND - Ground terminal
64 AVCC33 - Power supply terminal (+3.3V)
65 R1X1- I TMDS data (negative) input from the HDMI input selector
66 R1X1+ I TMDS data (positive) input from the HDMI input selector
67 AGND - Ground terminal
68 AVCC33 - Power supply terminal (+3.3V)
69 R1X2- I TMDS data (negative) input from the HDMI input selector
70 R1X2+ I TMDS data (positive) input from the HDMI input selector
71 AGND - Ground terminal
72 AVCC18 - Power supply terminal (+1.8V)
73 IOGND - Ground terminal
74 IOVCC33 - Power supply terminal (+3.3V)
75 MUTEOUT O Audio muting control signal output terminal
76, 77 RSVDNC - Not used
78 SPDIF O
S/PDIF signal output to the digital audio interface receiver, HDMI transmitter, DSP1 and DSP
controller
79 CGND - Ground terminal
80 CVCC18 - Power supply terminal (+1.8V)
81 to 84 SD0 to SD3 O PCM audio signal output to the HDMI transmitter and DSP1
85 WS O L/R sampling clock signal output to the HDMI transmitter, DSP1 and DSP2
86 SCK O Bit clock signal output to the HDMI transmitter, DSP1 and DSP2
87 IOGND - Ground terminal
88 IOVCC33 - Power supply terminal (+3.3V)
89 MCLK O
Master clock signal output to the D/A converter (for video section), HDMI transmitter, DSP1
and DSP2 (US and Canadian models)
Master clock signal output to the fi eld programmable gate array, HDMI transmitter, DSP1 and
DSP2 (AEP, Continental European, East European, Russian and UK models)
90 CGND - Ground terminal
91 CVCC18 - Power supply terminal (+1.8V)
92 DVCC18 - Power supply terminal (+1.8V)
93 DGND2 - Ground terminal
94 XTALOUT O System clock output terminal (28.322 MHz)
95 XTALIN I System clock input terminal (28.322 MHz)
96 XTALVCC - Power supply terminal (+3.3V)
97 REGVCC - Power supply terminal (+3.3V)
98 RSVDNC - Not used
99 RSVDL - Not used
100 RESET# I Reset signal input from the video system controller "L": reset
101 SCDT - Not used
102 INT O Interrupt signal output to the video system controller
103 IOGND - Ground terminal
104 IOVCC33 - Power supply terminal (+3.3V)
105 CI2CA - Not used
106 CGND - Ground terminal
107 CVCC18 - Power supply terminal (+1.8V)
108 to 111 Q35 to Q32 O Serial data output to the HDMI transmitter and video processor1
112 IOGND - Ground terminal
113 IOVCC33 - Power supply terminal (+3.3V)
114 to 117 Q31 to Q28 O Serial data output to the HDMI transmitter and video processor1
118 CGND - Ground terminal
119 CVCC18 - Power supply terminal (+1.8V)
120, 121 Q27, Q26 O Serial data output to the HDMI transmitter and video processor1
122, 123 Q25, Q24 O Serial data output to the HDMI transmitter
124 IOGND - Ground terminal
125 IOVCC33 - Power supply terminal (+3.3V)
126 to 129 Q23 to Q20 O Serial data output to the HDMI transmitter and video processor1
130 CGND - Ground terminal
