STR-DA5400ES
139
Pin No. Pin Name I/O Description
131 CVCC - Power supply terminal (+1.8V)
132 to 135 Q19 to Q16 O Serial data output to the HDMI transmitter and video processor1
136 IOGND - Ground terminal
137 IOVCC33 - Power supply terminal (+3.3V)
138 to 141 Q15 to Q12 O
Serial data output to the HDMI transmitter and video processor1
142 CGND -
Ground terminal
143 CVCC18 -
Power supply terminal (+1.8V)
144 Q11 O
Serial data output to the HDMI transmitter and video processor1
