STR-DA5400ES
148
Pin No. Pin Name I/O Description
102 AVDD - Power supply terminal (+3.3V)
103 R O Analog video (R) signal output to the video processor1
104 G O Analog video (G) signal output to the video processor1
105 B O Analog video (B) signal output to the video processor1
106 IREF I Reference voltage (+3.3V) input terminal
107 AVSS - Ground terminal
108 NC - Not used
109 VDD - Power supply terminal (+3.3V)
110 VSS - Ground terminal
111 to 116 DR0 to DR5 O Digital video (R) signal output terminal Not used
117 VSS - Ground terminal
118 VDD - Power supply terminal (+3.3V)
119 to 124 DG0 to DG5 O Digital video (G) signal output terminal Not used
125 VSS - Ground terminal
126 VDD - Power supply terminal (+3.3V)
127 to 132 DB0 to DB5 O Digital video (B) signal output terminal Not used
133 VSS - Ground terminal
134 FSC - Not used
135 YS_N - Not used
136 VSYNC_N O Vertical sync signal output to the video processor1
137 HSYNC_N O Horizontal sync signal output to the video processor1
138 BLANK_N O Blanking period signal output terminal Not used
139 DOTCLK O Dot clock signal output terminal Not used
140 VDD - Power supply terminal (+3.3V)
141 XIN I System clock input terminal (33.2 MHz)
142 XOUT O System clock output terminal (33.2 MHz)
143 VSS - Ground terminal
144 NC - Not used
